vpnc cannot connect to VPN due to vpnc-script
Matthew Martinez
I am trying to connect establish VPN connection with vpnc but it failed with message
Error: either "to" is duplicate, or "ipid" is a garbageAccording to I replaced vpnc-script but got a new error message:
/etc/vpnc/vpnc-script: 658: Syntax error: end of file unexpected (expecting ";;")After that it starts vpnc-connect "in background" but no IP address is assigned:
ifonfig -a:
tun0 Link encap:UNSPEC HWaddr 00-00-00-00-00-00-00-00-00-00-00-00-00-00-00-00 POINTOPOINT NOARP MULTICAST MTU:1500 Metric:1 RX packets:3 errors:0 dropped:0 overruns:0 frame:0 TX packets:0 errors:0 dropped:0 overruns:0 carrier:0 collisions:0 txqueuelen:500 RX bytes:531 (531.0 B) TX bytes:0 (0.0 B)uname -a:
Linux mobile 3.0.0-14-generic #23-Ubuntu SMP Mon Nov 21 20:28:43 UTC 2011 x86_64 x86_64 x86_64 GNU/LinuxIdeas?
Finally I got working version of vpnc-script here
23 Answers
I saw that this bug was fixed and relased only for Ubuntu Precise and I think you should mark it as affecting you and ask there for a possible solution to the problem in Oneiric (a merge of the released fix in Oneiric or another solution).
2i have the work around for the following error :
step 1: see what you need to do is, firstly take the backup of the vpnc script through the below command :
sudo cp /etc/vpnc/vpnc-script /etc/vpnc/vpnc-script.bckStep 2: now what you need to do is open the vpnc-script by any editor love to work with(vi, vim , emacs, gedit).
sudo gedit /etc/vpnc/vpnc-scriptand remove the content inside it and copy the content below :
#!/bin/sh
# List of parameters passed through environment
#* reason -- why this script was called, one of: pre-init connect disconnect
#* VPNGATEWAY -- vpn gateway address (always present)
#* TUNDEV -- tunnel device (always present)
#* INTERNAL_IP4_ADDRESS -- address (always present)
#* INTERNAL_IP4_MTU -- mtu (often unset)
#* INTERNAL_IP4_NETMASK -- netmask (often unset)
#* INTERNAL_IP4_NETMASKLEN -- netmask length (often unset)
#* INTERNAL_IP4_NETADDR -- address of network (only present if netmask is set)
#* INTERNAL_IP4_DNS -- list of dns servers
#* INTERNAL_IP4_NBNS -- list of wins servers
#* INTERNAL_IP6_ADDRESS -- IPv6 address
#* INTERNAL_IP6_NETMASK -- IPv6 netmask
#* INTERNAL_IP6_DNS -- IPv6 list of dns servers
#* CISCO_DEF_DOMAIN -- default domain name
#* CISCO_BANNER -- banner from server
#* CISCO_SPLIT_INC -- number of networks in split-network-list
#* CISCO_SPLIT_INC_%d_ADDR -- network address
#* CISCO_SPLIT_INC_%d_MASK -- subnet mask (for example: 255.255.255.0)
#* CISCO_SPLIT_INC_%d_MASKLEN -- subnet masklen (for example: 24)
#* CISCO_SPLIT_INC_%d_PROTOCOL -- protocol (often just 0)
#* CISCO_SPLIT_INC_%d_SPORT -- source port (often just 0)
#* CISCO_SPLIT_INC_%d_DPORT -- destination port (often just 0)
#* CISCO_IPV6_SPLIT_INC -- number of networks in IPv6 split-network-list
#* CISCO_IPV6_SPLIT_INC_%d_ADDR -- IPv6 network address
#* CISCO_IPV6_SPLIT_INC_$%d_MASKLEN -- IPv6 subnet masklen
# FIXMEs:
# Section A: route handling
# 1) The 3 values CISCO_SPLIT_INC_%d_PROTOCOL/SPORT/DPORT are currently being ignored
# In order to use them, we'll probably need os specific solutions
# * Linux: iptables -t mangle -I PREROUTING <conditions> -j ROUTE --oif $TUNDEV
# This would be an *alternative* to changing the routes (and thus 2) and 3)
# shouldn't be relevant at all)
# 2) There are two different functions to set routes: generic routes and the
# default route. Why isn't the defaultroute handled via the generic route case?
# 3) In the split tunnel case, all routes but the default route might get replaced
# without getting restored later. We should explicitely check and save them just
# like the defaultroute
# 4) Replies to a dhcp-server should never be sent into the tunnel
# Section B: Split DNS handling
# 1) Maybe dnsmasq can do something like that
# 2) Parse dns packets going out via tunnel and redirect them to original dns-server
#env | sort
#set -x
# =========== script (variable) setup ====================================
PATH=/sbin:/usr/sbin:$PATH
OS="`uname -s`"
HOOKS_DIR=/etc/vpnc
DEFAULT_ROUTE_FILE=/var/run/vpnc/defaultroute
RESOLV_CONF_BACKUP=/var/run/vpnc/resolv.conf-backup
SCRIPTNAME=`basename $0`
# some systems, eg. Darwin & FreeBSD, prune /var/run on boot
if [ ! -d "/var/run/vpnc" ]; then mkdir -p /var/run/vpnc [ -x /sbin/restorecon ] && /sbin/restorecon /var/run/vpnc
fi
# stupid SunOS: no blubber in /usr/local/bin ... (on stdout)
IPROUTE="`which ip | grep '^/'`" 2> /dev/null
if ifconfig --help 2>&1 | grep BusyBox > /dev/null; then ifconfig_syntax_inet=""
else ifconfig_syntax_inet="inet"
fi
if [ "$OS" = "Linux" ]; then ifconfig_syntax_ptp="pointopoint" route_syntax_gw="gw" route_syntax_del="del" route_syntax_netmask="netmask"
else ifconfig_syntax_ptp="" route_syntax_gw="" route_syntax_del="delete" route_syntax_netmask="-netmask"
fi
if [ "$OS" = "SunOS" ]; then route_syntax_interface="-interface" ifconfig_syntax_ptpv6="$INTERNAL_IP6_ADDRESS"
else route_syntax_interface="" ifconfig_syntax_ptpv6=""
fi
if [ -r /etc/openwrt_release ] && [ -n "$OPENWRT_INTERFACE" ]; then . /etc/functions.sh include /lib/network MODIFYRESOLVCONF=modify_resolvconf_openwrt RESTORERESOLVCONF=restore_resolvconf_openwrt
elif [ -x /sbin/resolvconf ]; then # Optional tool on Debian, Ubuntu, Gentoo MODIFYRESOLVCONF=modify_resolvconf_manager RESTORERESOLVCONF=restore_resolvconf_manager
elif [ -x /sbin/netconfig ]; then # tool on Suse after 11.1 MODIFYRESOLVCONF=modify_resolvconf_suse_netconfig RESTORERESOLVCONF=restore_resolvconf_suse_netconfig
elif [ -x /sbin/modify_resolvconf ]; then # Mandatory tool on Suse earlier than 11.1 MODIFYRESOLVCONF=modify_resolvconf_suse RESTORERESOLVCONF=restore_resolvconf_suse
else # Generic for any OS MODIFYRESOLVCONF=modify_resolvconf_generic RESTORERESOLVCONF=restore_resolvconf_generic
fi
# =========== script hooks =================================================
run_hooks() { HOOK="$1" if [ -d ${HOOKS_DIR}/${HOOK}.d ]; then for script in ${HOOKS_DIR}/${HOOK}.d/* ; do [ -f $script ] && . $script done fi
}
# =========== tunnel interface handling ====================================
do_ifconfig() { if [ -n "$INTERNAL_IP4_MTU" ]; then MTU=$INTERNAL_IP4_MTU elif [ -n "$IPROUTE" ]; then MTUDEV=`$IPROUTE route get "$VPNGATEWAY" | sed -ne 's/^.*dev \([a-z0-9]*\).*$/\1/p'` MTU=`$IPROUTE link show "$MTUDEV" | sed -ne 's/^.*mtu \([[:digit:]]\+\).*$/\1/p'` if [ -n "$MTU" ]; then MTU=`expr $MTU - 88` fi fi if [ -z "$MTU" ]; then MTU=1412 fi # Point to point interface require a netmask of 255.255.255.255 on some systems if [ -n "$IPROUTE" ]; then $IPROUTE link set dev "$TUNDEV" up mtu "$MTU" $IPROUTE addr add "$INTERNAL_IP4_ADDRESS/255.255.255.255" peer "$INTERNAL_IP4_ADDRESS" dev "$TUNDEV" else ifconfig "$TUNDEV" ${ifconfig_syntax_inet} "$INTERNAL_IP4_ADDRESS" $ifconfig_syntax_ptp "$INTERNAL_IP4_ADDRESS" netmask 255.255.255.255 mtu ${MTU} up fi if [ -n "$INTERNAL_IP4_NETMASK" ]; then set_network_route $INTERNAL_IP4_NETADDR $INTERNAL_IP4_NETMASK $INTERNAL_IP4_NETMASKLEN fi # If the netmask is provided, it contains the address _and_ netmask if [ -n "$INTERNAL_IP6_ADDRESS" ] && [ -z "$INTERNAL_IP6_NETMASK" ]; then INTERNAL_IP6_NETMASK="$INTERNAL_IP6_ADDRESS/128" fi if [ -n "$INTERNAL_IP6_NETMASK" ]; then if [ -n "$IPROUTE" ]; then $IPROUTE -6 addr add $INTERNAL_IP6_NETMASK dev $TUNDEV else # Unlike for Legacy IP, we don't specify the dest_address # here on *BSD. OpenBSD for one will refuse to accept # incoming packets to that address if we do. # OpenVPN does the same (gives dest_address for Legacy IP # but not for IPv6). # Only Solaris needs it; hence $ifconfig_syntax_ptpv6 ifconfig "$TUNDEV" inet6 $INTERNAL_IP6_NETMASK $ifconfig_syntax_ptpv6 mtu $MTU up fi fi
}
destroy_tun_device() { case "$OS" in NetBSD|FreeBSD) # and probably others... ifconfig "$TUNDEV" destroy ;; esac
}
# =========== route handling ====================================
if [ -n "$IPROUTE" ]; then fix_ip_get_output () { sed -e 's/ /\n/g' | \ sed -ne '1p;/via/{N;p};/dev/{N;p};/src/{N;p};/mtu/{N;p}' } set_vpngateway_route() { $IPROUTE route add `$IPROUTE route get "$VPNGATEWAY" | fix_ip_get_output` $IPROUTE route flush cache } del_vpngateway_route() { $IPROUTE route $route_syntax_del "$VPNGATEWAY" $IPROUTE route flush cache } set_default_route() { $IPROUTE route | grep '^default' | fix_ip_get_output > "$DEFAULT_ROUTE_FILE" $IPROUTE route replace default dev "$TUNDEV" $IPROUTE route flush cache } set_network_route() { NETWORK="$1" NETMASK="$2" NETMASKLEN="$3" $IPROUTE route replace "$NETWORK/$NETMASKLEN" dev "$TUNDEV" $IPROUTE route flush cache } reset_default_route() { if [ -s "$DEFAULT_ROUTE_FILE" ]; then $IPROUTE route replace `cat "$DEFAULT_ROUTE_FILE"` $IPROUTE route flush cache rm -f -- "$DEFAULT_ROUTE_FILE" fi } del_network_route() { NETWORK="$1" NETMASK="$2" NETMASKLEN="$3" $IPROUTE route $route_syntax_del "$NETWORK/$NETMASKLEN" dev "$TUNDEV" $IPROUTE route flush cache } set_ipv6_default_route() { # We don't save/restore IPv6 default route; just add a higher-priority one. $IPROUTE -6 route add default dev "$TUNDEV" metric 1 $IPROUTE -6 route flush cache } set_ipv6_network_route() { NETWORK="$1" NETMASKLEN="$2" $IPROUTE -6 route replace "$NETWORK/$NETMASKLEN" dev "$TUNDEV" $IPROUTE route flush cache } reset_ipv6_default_route() { $IPROUTE -6 route del default dev "$TUNDEV" $IPROUTE route flush cache } del_ipv6_network_route() { NETWORK="$1" NETMASKLEN="$2" $IPROUTE -6 route del "$NETWORK/$NETMASKLEN" dev "$TUNDEV" $IPROUTE -6 route flush cache }
else # use route command get_default_gw() { # isn't -n supposed to give --numeric output? # apperently not... # Get rid of lines containing IPv6 addresses (':') netstat -r -n | awk '/:/ { next; } /^(default|0\.0\.0\.0)/ { print $2; }' } set_vpngateway_route() { route add -host "$VPNGATEWAY" $route_syntax_gw "`get_default_gw`" } del_vpngateway_route() { route $route_syntax_del -host "$VPNGATEWAY" $route_syntax_gw "`get_default_gw`" } set_default_route() { DEFAULTGW="`get_default_gw`" echo "$DEFAULTGW" > "$DEFAULT_ROUTE_FILE" route $route_syntax_del default $route_syntax_gw "$DEFAULTGW" route add default $route_syntax_gw "$INTERNAL_IP4_ADDRESS" $route_syntax_interface } set_network_route() { NETWORK="$1" NETMASK="$2" NETMASKLEN="$3" del_network_route "$NETWORK" "$NETMASK" "$NETMASKLEN" route add -net "$NETWORK" $route_syntax_netmask "$NETMASK" $route_syntax_gw "$INTERNAL_IP4_ADDRESS" $route_syntax_interface } reset_default_route() { if [ -s "$DEFAULT_ROUTE_FILE" ]; then route $route_syntax_del default $route_syntax_gw "`get_default_gw`" $route_syntax_interface route add default $route_syntax_gw `cat "$DEFAULT_ROUTE_FILE"` rm -f -- "$DEFAULT_ROUTE_FILE" fi } del_network_route() { case "$OS" in Linux|NetBSD|Darwin|SunOS) # and probably others... # routes are deleted automatically on device shutdown return ;; esac NETWORK="$1" NETMASK="$2" NETMASKLEN="$3" route $route_syntax_del -net "$NETWORK" $route_syntax_netmask "$NETMASK" $route_syntax_gw "$INTERNAL_IP4_ADDRESS" } set_ipv6_default_route() { route add -inet6 default "$INTERNAL_IP6_ADDRESS" $route_syntax_interface } set_ipv6_network_route() { NETWORK="$1" NETMASK="$2" route add -inet6 -net "$NETWORK/$NETMASK" "$INTERNAL_IP6_ADDRESS" $route_syntax_interface : } reset_ipv6_default_route() { route $route_syntax_del -inet6 default "$INTERNAL_IP6_ADDRESS" : } del_ipv6_network_route() { NETWORK="$1" NETMASK="$2" route $route_syntax_del -inet6 "$NETWORK/$NETMASK" "$INTERNAL_IP6_ADDRESS" : }
fi
# =========== resolv.conf handling ====================================
# =========== resolv.conf handling for any OS =========================
modify_resolvconf_generic() { grep '^#@VPNC_GENERATED@' /etc/resolv.conf > /dev/null 2>&1 || cp -- /etc/resolv.conf "$RESOLV_CONF_BACKUP" NEW_RESOLVCONF="#@VPNC_GENERATED@ -- this file is generated by vpnc
# and will be overwritten by vpnc
# as long as the above mark is intact" # Remember the original value of CISCO_DEF_DOMAIN we need it later CISCO_DEF_DOMAIN_ORIG="$CISCO_DEF_DOMAIN" # Don't step on INTERNAL_IP4_DNS value, use a temporary variable INTERNAL_IP4_DNS_TEMP="$INTERNAL_IP4_DNS" exec 6< "$RESOLV_CONF_BACKUP" while read LINE <&6 ; do case "$LINE" in nameserver*) if [ -n "$INTERNAL_IP4_DNS_TEMP" ]; then read ONE_NAMESERVER INTERNAL_IP4_DNS_TEMP <<-EOF $INTERNAL_IP4_DNS_TEMP
EOF LINE="nameserver $ONE_NAMESERVER" else LINE="" fi ;; search*) if [ -n "$CISCO_DEF_DOMAIN" ]; then LINE="$LINE $CISCO_DEF_DOMAIN" CISCO_DEF_DOMAIN="" fi ;; domain*) if [ -n "$CISCO_DEF_DOMAIN" ]; then LINE="domain $CISCO_DEF_DOMAIN" CISCO_DEF_DOMAIN="" fi ;; esac NEW_RESOLVCONF="$NEW_RESOLVCONF
$LINE" done exec 6<&- for i in $INTERNAL_IP4_DNS_TEMP ; do NEW_RESOLVCONF="$NEW_RESOLVCONF
nameserver $i" done if [ -n "$CISCO_DEF_DOMAIN" ]; then NEW_RESOLVCONF="$NEW_RESOLVCONF
search $CISCO_DEF_DOMAIN" fi echo "$NEW_RESOLVCONF" > /etc/resolv.conf if [ "$OS" = "Darwin" ]; then case "`uname -r`" in # Skip for pre-10.4 systems 4.*|5.*|6.*|7.*) ;; # 10.4 and later require use of scutil for DNS to work properly *) OVERRIDE_PRIMARY="" if [ -n "$CISCO_SPLIT_INC" ]; then if [ $CISCO_SPLIT_INC -lt 1 ]; then # Must override for correct default route # Cannot use multiple DNS matching in this case OVERRIDE_PRIMARY='d.add OverridePrimary # 1' fi fi # Uncomment the following if/fi pair to use multiple # DNS matching when available. When multiple DNS matching # is present, anything reading the /etc/resolv.conf file # directly will probably not work as intended. #if [ -z "$CISCO_DEF_DOMAIN_ORIG" ]; then # Cannot use multiple DNS matching without a domain OVERRIDE_PRIMARY='d.add OverridePrimary # 1' #fi scutil >/dev/null 2>&1 <<-EOF open d.init d.add ServerAddresses * $INTERNAL_IP4_DNS set State:/Network/Service/$TUNDEV/DNS d.init # next line overrides the default gateway and breaks split routing # d.add Router $INTERNAL_IP4_ADDRESS d.add Addresses * $INTERNAL_IP4_ADDRESS d.add SubnetMasks * 255.255.255.255 d.add InterfaceName $TUNDEV $OVERRIDE_PRIMARY set State:/Network/Service/$TUNDEV/IPv4 close EOF if [ -n "$CISCO_DEF_DOMAIN_ORIG" ]; then scutil >/dev/null 2>&1 <<-EOF open get State:/Network/Service/$TUNDEV/DNS d.add DomainName $CISCO_DEF_DOMAIN_ORIG d.add SearchDomains * $CISCO_DEF_DOMAIN_ORIG d.add SupplementalMatchDomains * $CISCO_DEF_DOMAIN_ORIG set State:/Network/Service/$TUNDEV/DNS close EOF fi ;; esac fi
}
restore_resolvconf_generic() { if [ ! -f "$RESOLV_CONF_BACKUP" ]; then return fi grep '^#@VPNC_GENERATED@' /etc/resolv.conf > /dev/null 2>&1 && cat "$RESOLV_CONF_BACKUP" > /etc/resolv.conf rm -f -- "$RESOLV_CONF_BACKUP" if [ "$OS" = "Darwin" ]; then case "`uname -r`" in # Skip for pre-10.4 systems 4.*|5.*|6.*|7.*) ;; # 10.4 and later require use of scutil for DNS to work properly *) scutil >/dev/null 2>&1 <<-EOF open remove State:/Network/Service/$TUNDEV/IPv4 remove State:/Network/Service/$TUNDEV/DNS close EOF ;; esac fi
}
# === resolv.conf handling via /sbin/netconfig (Suse 11.1) =====================
# Suse provides a script that modifies resolv.conf. Use it because it will
# restart/reload all other services that care about it (e.g. lwresd). [unclear if this is still true, but probably --mlk]
modify_resolvconf_suse_netconfig()
{ /sbin/netconfig modify -s vpnc -i "$TUNDEV" <<-EOF INTERFACE='$TUNDEV' DNSSERVERS='$INTERNAL_IP4_DNS' DNSDOMAIN='$CISCO_DEF_DOMAIN' EOF
}
# Restore resolv.conf to old contents on Suse
restore_resolvconf_suse_netconfig()
{ /sbin/netconfig remove -s vpnc -i "$TUNDEV"
}
# === resolv.conf handling via /sbin/modify_resolvconf (Suse) =====================
# Suse provides a script that modifies resolv.conf. Use it because it will
# restart/reload all other services that care about it (e.g. lwresd).
modify_resolvconf_suse()
{ FULL_SCRIPTNAME=`readlink -f $0` RESOLV_OPTS='' test -n "$INTERNAL_IP4_DNS" && RESOLV_OPTS="-n \"$INTERNAL_IP4_DNS\"" test -n "$CISCO_DEF_DOMAIN" && RESOLV_OPTS="$RESOLV_OPTS -d $CISCO_DEF_DOMAIN" test -n "$RESOLV_OPTS" && eval /sbin/modify_resolvconf modify -s vpnc -p $SCRIPTNAME -f $FULL_SCRIPTNAME -e $TUNDEV $RESOLV_OPTS -t \"This file was created by $SCRIPTNAME\"
}
# Restore resolv.conf to old contents on Suse
restore_resolvconf_suse()
{ FULL_SCRIPTNAME=`readlink -f $0` /sbin/modify_resolvconf restore -s vpnc -p $SCRIPTNAME -f $FULL_SCRIPTNAME -e $TUNDEV
}
# === resolv.conf handling via UCI (OpenWRT) =========
modify_resolvconf_openwrt() { add_dns $OPENWRT_INTERFACE $INTERNAL_IP4_DNS
}
restore_resolvconf_openwrt() { remove_dns $OPENWRT_INTERFACE
}
# === resolv.conf handling via /sbin/resolvconf (Debian, Ubuntu, Gentoo)) =========
modify_resolvconf_manager() { NEW_RESOLVCONF="" for i in $INTERNAL_IP4_DNS; do NEW_RESOLVCONF="$NEW_RESOLVCONF
nameserver $i" done if [ -n "$CISCO_DEF_DOMAIN" ]; then NEW_RESOLVCONF="$NEW_RESOLVCONF
domain $CISCO_DEF_DOMAIN" fi echo "$NEW_RESOLVCONF" | /sbin/resolvconf -a $TUNDEV
}
restore_resolvconf_manager() { /sbin/resolvconf -d $TUNDEV
}
# ========= Toplevel state handling =======================================
kernel_is_2_6_or_above() { case `uname -r` in 1.*|2.[012345]*) return 1 ;; *) return 0 ;; esac
}
do_pre_init() { if [ "$OS" = "Linux" ]; then if (exec 6<> /dev/net/tun) > /dev/null 2>&1 ; then : else # can't open /dev/net/tun test -e /proc/sys/kernel/modprobe && `cat /proc/sys/kernel/modprobe` tun 2>/dev/null # fix for broken devfs in kernel 2.6.x if [ "`readlink /dev/net/tun`" = misc/net/tun \ -a ! -e /dev/net/misc/net/tun -a -e /dev/misc/net/tun ] ; then ln -sf /dev/misc/net/tun /dev/net/tun fi # make sure tun device exists if [ ! -e /dev/net/tun ]; then mkdir -p /dev/net mknod -m 0640 /dev/net/tun c 10 200 [ -x /sbin/restorecon ] && /sbin/restorecon /dev/net/tun fi # workaround for a possible latency caused by udev, sleep max. 10s if kernel_is_2_6_or_above ; then for x in `seq 100` ; do (exec 6<> /dev/net/tun) > /dev/null 2>&1 && break; sleep 0.1 done fi fi elif [ "$OS" = "FreeBSD" ]; then if [ ! -e /dev/tun ]; then kldload if_tun fi elif [ "$OS" = "GNU/kFreeBSD" ]; then if [ ! -e /dev/tun ]; then kldload if_tun fi elif [ "$OS" = "NetBSD" ]; then : elif [ "$OS" = "OpenBSD" ]; then : elif [ "$OS" = "SunOS" ]; then : elif [ "$OS" = "Darwin" ]; then : fi
}
do_connect() { if [ -n "$CISCO_BANNER" ]; then echo "Connect Banner:" echo "$CISCO_BANNER" | while read LINE ; do echo "|" "$LINE" ; done echo fi set_vpngateway_route do_ifconfig if [ -n "$CISCO_SPLIT_INC" ]; then i=0 while [ $i -lt $CISCO_SPLIT_INC ] ; do eval NETWORK="\${CISCO_SPLIT_INC_${i}_ADDR}" eval NETMASK="\${CISCO_SPLIT_INC_${i}_MASK}" eval NETMASKLEN="\${CISCO_SPLIT_INC_${i}_MASKLEN}" if [ $NETWORK != "0.0.0.0" ]; then set_network_route "$NETWORK" "$NETMASK" "$NETMASKLEN" else set_default_route fi i=`expr $i + 1` done for i in $INTERNAL_IP4_DNS ; do echo "$i" | grep : >/dev/null || \ set_network_route "$i" "255.255.255.255" "32" done elif [ -n "$INTERNAL_IP4_ADDRESS" ]; then set_default_route fi if [ -n "$CISCO_IPV6_SPLIT_INC" ]; then i=0 while [ $i -lt $CISCO_IPV6_SPLIT_INC ] ; do eval NETWORK="\${CISCO_IPV6_SPLIT_INC_${i}_ADDR}" eval NETMASKLEN="\${CISCO_IPV6_SPLIT_INC_${i}_MASKLEN}" if [ $NETMASKLEN -lt 128 ]; then set_ipv6_network_route "$NETWORK" "$NETMASKLEN" else set_ipv6_default_route fi i=`expr $i + 1` done for i in $INTERNAL_IP4_DNS ; do if echo "$i" | grep : >/dev/null; then set_ipv6_network_route "$i" "128" fi done elif [ -n "$INTERNAL_IP6_NETMASK" -o -n "$INTERNAL_IP6_ADDRESS" ]; then set_ipv6_default_route fi if [ -n "$INTERNAL_IP4_DNS" ]; then $MODIFYRESOLVCONF fi
}
do_disconnect() { if [ -n "$CISCO_SPLIT_INC" ]; then i=0 while [ $i -lt $CISCO_SPLIT_INC ] ; do eval NETWORK="\${CISCO_SPLIT_INC_${i}_ADDR}" eval NETMASK="\${CISCO_SPLIT_INC_${i}_MASK}" eval NETMASKLEN="\${CISCO_SPLIT_INC_${i}_MASKLEN}" if [ $NETWORK != "0.0.0.0" ]; then # FIXME: This doesn't restore previously overwritten # routes. del_network_route "$NETWORK" "$NETMASK" "$NETMASKLEN" else reset_default_route fi i=`expr $i + 1` done for i in $INTERNAL_IP4_DNS ; do del_network_route "$i" "255.255.255.255" "32" done else reset_default_route fi if [ -n "$CISCO_IPV6_SPLIT_INC" ]; then i=0 while [ $i -lt $CISCO_IPV6_SPLIT_INC ] ; do eval NETWORK="\${CISCO_IPV6_SPLIT_INC_${i}_ADDR}" eval NETMASKLEN="\${CISCO_IPV6_SPLIT_INC_${i}_MASKLEN}" if [ $NETMASKLEN -eq 0 ]; then reset_ipv6_default_route else del_ipv6_network_route "$NETWORK" "$NETMASKLEN" fi i=`expr $i + 1` done for i in $INTERNAL_IP6_DNS ; do del_ipv6_network_route "$i" "128" done elif [ -n "$INTERNAL_IP6_NETMASK" -o -n "$INTERNAL_IP6_ADDRESS" ]; then reset_ipv6_default_route fi del_vpngateway_route if [ -n "$INTERNAL_IP4_DNS" ]; then $RESTORERESOLVCONF fi destroy_tun_device
}
#### Main
if [ -z "$reason" ]; then echo "this script must be called from vpnc" 1>&2 exit 1
fi
case "$reason" in pre-init) run_hooks pre-init do_pre_init ;; connect) run_hooks connect do_connect run_hooks post-connect ;; disconnect) run_hooks disconnect do_disconnect run_hooks post-disconnect ;; reconnect) run_hooks reconnect ;; *) echo "unknown reason '$reason'. Maybe vpnc-script is out of date" 1>&2 exit 1 ;;
esac
exit 0
****************************************************************************************save and close the vpnc-script file.
Step 3: run the vpnc now, you want get the ipid error now.
Note: see if you replace the vpnc-script file as done in above example you will get error because it change the flag set onto the file. So, we just only need to change is the content of the vpnc-script file.
Cheers!!
-Simranjeet
1This issue exists in Ubuntu 20 upgraded from 18. Remove the first line which is commented in the file /etc/resolv.conf file.
1
