Ubuntu server 20.04.3 LTS fail to install with virtio block
Matthew Barrera
As usual, I want to create a VM with VirtIO Block on my Proxmox server but since a month the installation fail, but if I choose SCSI as bus it work.
I have kubuntu, xubuntu, debian, openmediavault and univention all installed with the same virtual configuration which is mainly all virtIO
- cpu: host
- hd: virtio with cache write-back and discard option enabled
- lan: virtio and they all work well.
for my ubuntu server I tried
- hd: virtio with cache write-back and discard option enabled
- hd: virtio with cache default (no cache) and discard option enabled
- hd: virtio with cache default (no cache) and discard option disabled
- hd: scsi with cache write-back and discard option enabled
and it only works when I choose SCSI which it is new for me, because since 16.04 I always installed my Ubuntu server with virtio
Does anybody experience a similar situation ?
here the end of crash log:
since I'm limited to 30000 charaters
ProblemType: Bug
ApportVersion: 2.20.11-0ubuntu27.18
Architecture: amd64
CasperMD5CheckResult: pass
CasperVersion: 1.445.1
CrashDB: {'impl': 'launchpad', 'project': 'subiquity'}
CurrentDmesg: [ 35.751320] cfg80211: Loaded X.509 cert 'sforshee: 00b28ddf47aef9cea7' [ 35.751765] platform regulatory.0: Direct firmware load for regulatory.db failed with error -2 [ 35.751767] cfg80211: failed to load regulatory.db [ 54.550250] random: crng init done [ 54.550257] random: 7 urandom warning(s) missed due to ratelimiting [ 79.950142] spl: loading out-of-tree module taints kernel. [ 79.956479] znvpair: module license 'CDDL' taints kernel. [ 79.956484] Disabling lock debugging due to kernel taint [ 81.313577] ZFS: Loaded module v0.8.3-1ubuntu12.10, ZFS pool version 5000, ZFS filesystem version 5 [ 82.807182] vda: vda1 [ 82.845943] vda: vda1 [ 83.026886] vda: vda1 [ 83.119956] vda: vda1 [ 84.155003] vda: vda1 vda2 [ 84.409820] vda: vda1 vda2 [ 84.588285] vda: vda1 vda2 [ 85.418382] vda: vda1 vda2 [ 85.594429] vda: vda1 vda2 [ 85.726449] EXT4-fs (vda2): mounted filesystem with ordered data mode. Opts: (null) [ 90.027581] blk_update_request: I/O error, dev vda, sector 50638816 op 0x1:(WRITE) flags 0x0 phys_seg 52 prio class 0 [ 90.027586] EXT4-fs warning (device vda2): ext4_end_bio:309: I/O error 10 writing to inode 1573538 (offset 0 size 3096576 starting block 6329856) [ 90.027587] Buffer I/O error on device vda2, logical block 6328700 [ 90.027588] Buffer I/O error on device vda2, logical block 6328701 [ 90.027588] Buffer I/O error on device vda2, logical block 6328702 [ 90.027589] Buffer I/O error on device vda2, logical block 6328703 [ 90.027589] Buffer I/O error on device vda2, logical block 6328704 [ 90.027590] Buffer I/O error on device vda2, logical block 6328705 [ 90.027590] Buffer I/O error on device vda2, logical block 6328706 [ 90.027591] Buffer I/O error on device vda2, logical block 6328707 [ 90.027591] Buffer I/O error on device vda2, logical block 6328708 [ 90.027592] Buffer I/O error on device vda2, logical block 6328709 [ 90.027713] EXT4-fs warning (device vda2): ext4_end_bio:309: I/O error 10 writing to inode 1573538 (offset 0 size 3096576 starting block 6329968) [ 90.027736] blk_update_request: I/O error, dev vda, sector 50639744 op 0x1:(WRITE) flags 0x4000 phys_seg 80 prio class 0 [ 90.027737] blk_update_request: I/O error, dev vda, sector 50642304 op 0x1:(WRITE) flags 0x4000 phys_seg 65 prio class 0 [ 90.027738] EXT4-fs warning (device vda2): ext4_end_bio:309: I/O error 10 writing to inode 1573539 (offset 0 size 1773568 starting block 6330401) [ 90.027818] EXT4-fs warning (device vda2): ext4_end_bio:309: I/O error 10 writing to inode 1573540 (offset 0 size 90112 starting block 6330423) [ 90.027824] blk_update_request: I/O error, dev vda, sector 50643384 op 0x1:(WRITE) flags 0x4000 phys_seg 145 prio class 0 [ 90.027825] EXT4-fs warning (device vda2): ext4_end_bio:309: I/O error 10 writing to inode 1573541 (offset 0 size 1069056 starting block 6330684) [ 90.027880] blk_update_request: I/O error, dev vda, sector 50645472 op 0x1:(WRITE) flags 0x0 phys_seg 50 prio class 0 [ 90.027881] EXT4-fs warning (device vda2): ext4_end_bio:309: I/O error 10 writing to inode 1573542 (offset 0 size 421888 starting block 6330787) [ 90.027906] EXT4-fs warning (device vda2): ext4_end_bio:309: I/O error 10 writing to inode 1573543 (offset 0 size 167936 starting block 6330828) [ 90.027921] EXT4-fs warning (device vda2): ext4_end_bio:309: I/O error 10 writing to inode 1573544 (offset 0 size 208896 starting block 6330879) [ 90.027932] blk_update_request: I/O error, dev vda, sector 50647032 op 0x1:(WRITE) flags 0x4000 phys_seg 129 prio class 0 [ 90.027933] EXT4-fs warning (device vda2): ext4_end_bio:309: I/O error 10 writing to inode 1573546 (offset 0 size 897024 starting block 6331098) [ 90.027978] EXT4-fs warning (device vda2): ext4_end_bio:309: I/O error 10 writing to inode 1573547 (offset 0 size 180224 starting block 6331142) [ 90.027989] blk_update_request: I/O error, dev vda, sector 50649208 op 0x1:(WRITE) flags 0x4000 phys_seg 165 prio class 0 [ 90.028053] blk_update_request: I/O error, dev vda, sector 50651600 op 0x1:(WRITE) flags 0x0 phys_seg 139 prio class 0 [ 90.028112] blk_update_request: I/O error, dev vda, sector 50653328 op 0x1:(WRITE) flags 0x0 phys_seg 3 prio class 0 [ 90.028130] blk_update_request: I/O error, dev vda, sector 50653352 op 0x1:(WRITE) flags 0x0 phys_seg 2 prio class 0 [ 91.468992] JBD2: Detected IO errors while flushing file data on vda2-8 [ 100.046024] print_req_error: 9 callbacks suppressed [ 100.046028] blk_update_request: I/O error, dev vda, sector 577536 op 0x1:(WRITE) flags 0x4000 phys_seg 74 prio class 0 [ 100.051424] blk_update_request: I/O error, dev vda, sector 580096 op 0x1:(WRITE) flags 0x4000 phys_seg 120 prio class 0 [ 100.051428] blk_update_request: I/O error, dev vda, sector 582656 op 0x1:(WRITE) flags 0x0 phys_seg 63 prio class 0 [ 100.051430] EXT4-fs warning: 72 callbacks suppressed [ 100.051444] EXT4-fs warning (device vda2): ext4_end_bio:309: I/O error 10 writing to inode 1579404 (offset 0 size 8388608 starting block 72904) [ 100.051446] buffer_io_error: 3281 callbacks suppressed [ 100.051447] Buffer I/O error on device vda2, logical block 71680 [ 100.051450] Buffer I/O error on device vda2, logical block 71681 [ 100.051450] Buffer I/O error on device vda2, logical block 71682 [ 100.051451] Buffer I/O error on device vda2, logical block 71683 [ 100.051451] Buffer I/O error on device vda2, logical block 71684 [ 100.051452] Buffer I/O error on device vda2, logical block 71685 [ 100.051452] Buffer I/O error on device vda2, logical block 71686 [ 100.051453] Buffer I/O error on device vda2, logical block 71687 [ 100.051453] Buffer I/O error on device vda2, logical block 71688 [ 100.051454] Buffer I/O error on device vda2, logical block 71689 [ 100.051607] blk_update_request: I/O error, dev vda, sector 583232 op 0x1:(WRITE) flags 0x4000 phys_seg 189 prio class 0 [ 100.051608] blk_update_request: I/O error, dev vda, sector 585792 op 0x1:(WRITE) flags 0x0 phys_seg 67 prio class 0 [ 100.051610] EXT4-fs warning (device vda2): ext4_end_bio:309: I/O error 10 writing to inode 1579404 (offset 0 size 8388608 starting block 73429) [ 100.051727] blk_update_request: I/O error, dev vda, sector 587432 op 0x1:(WRITE) flags 0x4000 phys_seg 123 prio class 0 [ 100.051728] blk_update_request: I/O error, dev vda, sector 589992 op 0x1:(WRITE) flags 0x4000 phys_seg 134 prio class 0 [ 100.051730] EXT4-fs warning (device vda2): ext4_end_bio:309: I/O error 10 writing to inode 1579404 (offset 0 size 8388608 starting block 73991) [ 100.051859] blk_update_request: I/O error, dev vda, sector 591928 op 0x1:(WRITE) flags 0x0 phys_seg 77 prio class 0 [ 100.051860] EXT4-fs warning (device vda2): ext4_end_bio:309: I/O error 10 writing to inode 1579404 (offset 0 size 8388608 starting block 74240) [ 100.051913] blk_update_request: I/O error, dev vda, sector 593920 op 0x1:(WRITE) flags 0x4000 phys_seg 73 prio class 0 [ 100.051915] blk_update_request: I/O error, dev vda, sector 596480 op 0x1:(WRITE) flags 0x4000 phys_seg 161 prio class 0 [ 100.051916] EXT4-fs warning (device vda2): ext4_end_bio:309: I/O error 10 writing to inode 1579404 (offset 8388608 size 8388608 starting block 74903) [ 100.052054] EXT4-fs warning (device vda2): ext4_end_bio:309: I/O error 10 writing to inode 1579404 (offset 8388608 size 8388608 starting block 75776) [ 101.472031] JBD2: Detected IO errors while flushing file data on vda2-8 [ 112.542468] print_req_error: 4 callbacks suppressed [ 112.542470] blk_update_request: I/O error, dev vda, sector 770064 op 0x1:(WRITE) flags 0x4000 phys_seg 177 prio class 0 [ 112.542474] EXT4-fs warning (device vda2): ext4_end_bio:309: I/O error 10 writing to inode 4208 (offset 0 size 176128 starting block 96301) [ 112.542475] buffer_io_error: 3574 callbacks suppressed [ 112.542476] Buffer I/O error on device vda2, logical block 95746 [ 112.542478] Buffer I/O error on device vda2, logical block 95747 [ 112.542479] Buffer I/O error on device vda2, logical block 95748 [ 112.542480] Buffer I/O error on device vda2, logical block 95749 [ 112.542480] Buffer I/O error on device vda2, logical block 95750 [ 112.542481] Buffer I/O error on device vda2, logical block 95751 [ 112.542481] Buffer I/O error on device vda2, logical block 95752 [ 112.542482] Buffer I/O error on device vda2, logical block 95753 [ 112.542483] Buffer I/O error on device vda2, logical block 95754 [ 112.542490] Buffer I/O error on device vda2, logical block 95755 [ 112.542499] EXT4-fs warning (device vda2): ext4_end_bio:309: I/O error 10 writing to inode 4209 (offset 0 size 192512 starting block 96348) [ 112.542511] EXT4-fs warning (device vda2): ext4_end_bio:309: I/O error 10 writing to inode 4210 (offset 0 size 180224 starting block 96392) [ 112.542521] EXT4-fs warning (device vda2): ext4_end_bio:309: I/O error 10 writing to inode 4211 (offset 0 size 188416 starting block 96438) [ 112.542532] EXT4-fs warning (device vda2): ext4_end_bio:309: I/O error 10 writing to inode 4212 (offset 0 size 184320 starting block 96483) [ 112.542544] EXT4-fs warning (device vda2): ext4_end_bio:309: I/O error 10 writing to inode 4213 (offset 0 size 184320 starting block 96528) [ 112.542557] blk_update_request: I/O error, dev vda, sector 772224 op 0x1:(WRITE) flags 0x4000 phys_seg 215 prio class 0 [ 112.542559] EXT4-fs warning (device vda2): ext4_end_bio:309: I/O error 10 writing to inode 4214 (offset 0 size 208896 starting block 96579) [ 112.542572] EXT4-fs warning (device vda2): ext4_end_bio:309: I/O error 10 writing to inode 4215 (offset 0 size 180224 starting block 96623) [ 112.542582] EXT4-fs warning (device vda2): ext4_end_bio:309: I/O error 10 writing to inode 4216 (offset 0 size 163840 starting block 96663) [ 112.542592] EXT4-fs warning (device vda2): ext4_end_bio:309: I/O error 10 writing to inode 4217 (offset 0 size 12288 starting block 96666) [ 112.542723] blk_update_request: I/O error, dev vda, sector 774760 op 0x1:(WRITE) flags 0x4000 phys_seg 164 prio class 0 [ 112.542799] blk_update_request: I/O error, dev vda, sector 777248 op 0x1:(WRITE) flags 0x4000 phys_seg 237 prio class 0 [ 112.542865] blk_update_request: I/O error, dev vda, sector 779704 op 0x1:(WRITE) flags 0x0 phys_seg 44 prio class 0 [ 112.542877] blk_update_request: I/O error, dev vda, sector 780152 op 0x1:(WRITE) flags 0x0 phys_seg 39 prio class 0 [ 112.542903] blk_update_request: I/O error, dev vda, sector 780552 op 0x1:(WRITE) flags 0x0 phys_seg 5 prio class 0 [ 112.542909] blk_update_request: I/O error, dev vda, sector 780600 op 0x1:(WRITE) flags 0x4000 phys_seg 132 prio class 0 [ 112.542984] blk_update_request: I/O error, dev vda, sector 782304 op 0x1:(WRITE) flags 0x4000 phys_seg 79 prio class 0 [ 112.543055] blk_update_request: I/O error, dev vda, sector 784688 op 0x1:(WRITE) flags 0x4000 phys_seg 129 prio class 0 [ 113.523162] JBD2: Detected IO errors while flushing file data on vda2-8 [ 118.385475] JBD2: Detected IO errors while flushing file data on vda2-8 [ 119.362413] print_req_error: 54 callbacks suppressed [ 119.362415] blk_update_request: I/O error, dev vda, sector 887840 op 0x1:(WRITE) flags 0x0 phys_seg 59 prio class 0 [ 119.362420] EXT4-fs warning: 260 callbacks suppressed [ 119.362422] EXT4-fs warning (device vda2): ext4_end_bio:309: I/O error 10 writing to inode 528665 (offset 0 size 8388608 starting block 111081) [ 119.362423] buffer_io_error: 15434 callbacks suppressed [ 119.362423] Buffer I/O error on device vda2, logical block 110148 [ 119.362424] Buffer I/O error on device vda2, logical block 110149 [ 119.362424] Buffer I/O error on device vda2, logical block 110150 [ 119.362425] Buffer I/O error on device vda2, logical block 110151 [ 119.362426] Buffer I/O error on device vda2, logical block 110152 [ 119.362426] Buffer I/O error on device vda2, logical block 110153 [ 119.362426] Buffer I/O error on device vda2, logical block 110154 [ 119.362427] Buffer I/O error on device vda2, logical block 110155 [ 119.362428] Buffer I/O error on device vda2, logical block 110156 [ 119.362428] Buffer I/O error on device vda2, logical block 110157 [ 119.362539] EXT4-fs warning (device vda2): ext4_end_bio:309: I/O error 10 writing to inode 528665 (offset 0 size 8388608 starting block 111104) [ 119.362546] blk_update_request: I/O error, dev vda, sector 888832 op 0x1:(WRITE) flags 0x4000 phys_seg 112 prio class 0 [ 119.362553] blk_update_request: I/O error, dev vda, sector 891392 op 0x1:(WRITE) flags 0x0 phys_seg 144 prio class 0 [ 119.362556] EXT4-fs warning (device vda2): ext4_end_bio:309: I/O error 10 writing to inode 528665 (offset 8388608 size 8388608 starting block 111724) [ 119.362735] blk_update_request: I/O error, dev vda, sector 893792 op 0x1:(WRITE) flags 0x4000 phys_seg 106 prio class 0 [ 119.362736] blk_update_request: I/O error, dev vda, sector 896352 op 0x1:(WRITE) flags 0x4000 phys_seg 110 prio class 0 [ 119.362738] blk_update_request: I/O error, dev vda, sector 898912 op 0x1:(WRITE) flags 0x0 phys_seg 42 prio class 0 [ 119.362739] EXT4-fs warning (device vda2): ext4_end_bio:309: I/O error 10 writing to inode 528665 (offset 8388608 size 8388608 starting block 112528) [ 119.362904] blk_update_request: I/O error, dev vda, sector 900224 op 0x1:(WRITE) flags 0x4000 phys_seg 191 prio class 0 [ 119.362905] blk_update_request: I/O error, dev vda, sector 902784 op 0x1:(WRITE) flags 0x0 phys_seg 98 prio class 0 [ 119.362906] EXT4-fs warning (device vda2): ext4_end_bio:309: I/O error 10 writing to inode 528665 (offset 8388608 size 8388608 starting block 113068) [ 119.363045] EXT4-fs warning (device vda2): ext4_end_bio:309: I/O error 10 writing to inode 528665 (offset 8388608 size 8388608 starting block 113152) [ 119.363062] blk_update_request: I/O error, dev vda, sector 905216 op 0x1:(WRITE) flags 0x4000 phys_seg 97 prio class 0 [ 119.363064] blk_update_request: I/O error, dev vda, sector 907776 op 0x1:(WRITE) flags 0x0 phys_seg 159 prio class 0 [ 119.363065] EXT4-fs warning (device vda2): ext4_end_bio:309: I/O error 10 writing to inode 528665 (offset 16777216 size 8388608 starting block 113739) [ 119.363182] EXT4-fs warning (device vda2): ext4_end_bio:309: I/O error 10 writing to inode 528665 (offset 16777216 size 8388608 starting block 114486) [ 119.363326] EXT4-fs warning (device vda2): ext4_end_bio:309: I/O error 10 writing to inode 528665 (offset 16777216 size 8388608 starting block 114873) [ 119.363426] EXT4-fs warning (device vda2): ext4_end_bio:309: I/O error 10 writing to inode 528665 (offset 16777216 size 8388608 starting block 115200) [ 124.734771] JBD2: Detected IO errors while flushing file data on vda2-8
CurtinConfig: # Autogenerated by Subiquity: 2021-11-16 02:22:39.372259 UTC apt: preserve_sources_list: false primary: - arches: [amd64, i386] uri: - arches: [default] uri: curthooks_commands: 001-configure-apt: [/snap/subiquity/2651/bin/subiquity-configure-apt, /snap/subiquity/2651/usr/bin/python3, 'true'] debconf_selections: {subiquity: ''} grub: {probe_additional_os: true, terminal: unmodified} install: {save_install_config: /var/log/installer/curtin-install-cfg.yaml, save_install_log: /var/log/installer/curtin-install.log, target: /target, unmount: disabled} kernel: {package: linux-generic} pollinate: user_agent: {subiquity: 21.08.2_2651} reporting: subiquity: {identifier: curtin_event.1862, type: journald} sources: {ubuntu00: 'cp:///media/filesystem'} stages: [early, partitioning, extract, curthooks, hook, late] storage: config: - {ptable: gpt, path: /dev/vda, wipe: superblock-recursive, preserve: false, name: '', grub_device: true, type: disk, id: disk-vda} - {device: disk-vda, size: 1048576, flag: bios_grub, number: 1, preserve: false, grub_device: false, type: partition, id: partition-0} - {device: disk-vda, size: 34356592640, wipe: superblock, flag: '', number: 2, preserve: false, grub_device: false, type: partition, id: partition-1} - {fstype: ext4, volume: partition-1, preserve: false, type: format, id: format-0} - {path: /, device: format-0, type: mount, id: mount-0} version: 1 verbosity: 3 write_files: etc_default_keyboard: {content: '# KEYBOARD CONFIGURATION FILE # Consult the keyboard(5) manual page. XKBMODEL="pc105" XKBLAYOUT="us" XKBVARIANT="" XKBOPTIONS="" BACKSPACE="guess" ', path: etc/default/keyboard, permissions: 420} etc_machine_id: {content: '81353fe4a9d14f0b8c12ba202ea7daff ', path: etc/machine-id, permissions: 292} etc_netplan_installer: {content: "# This is the network config written by 'subiquity'\n\ network:\n ethernets:\n ens18:\n dhcp4: true\n version: 2\n", path: etc/netplan/00-installer-config.yaml} md5check: {content: "{\n \"checksum_missmatch\": [\n],\n \"result\": \"pass\"\n\ }\n", path: var/log/installer/casper-md5check.json, permissions: 420} media_info: {content: Ubuntu-Server 20.04.3 LTS "Focal Fossa" - Release amd64 (20210824), path: var/log/installer/media-info, permissions: 420} nonet: {content: 'network: {config: disabled} ', path: etc/cloud/cloud.cfg.d/subiquity-disable-cloudinit-networking.cfg}
CurtinErrors: curtin-logs-2021-11-16-02-23/ps: yes after several try I sent the log to canonical ;)
