My Ubuntu 20.04 system has been affected by occasional freezes (~ each 1-2 days) which completely blocks any interaction (not even REISUB works) and requires pressing on the power button to restart the computer. This is a brand new installation on a laptop MSI GF65 Thin 10SER. I have done some research already and this seems to be an old problem (, , ) related to the Intel iGPU.

My dmesg is full of lines such as the ones below and inevitably they cause the system to freeze.

[drm:intel_pipe_update_end [i915]] *ERROR* Atomic update failure on pipe A (start=9338 end=9339) time 321 us, min 1063, max 1079, scanline start 1038, end 1090

$ uname -r

5.4.0-58-generic

$ lspci -k | grep -EA3 'VGA|3D|Display':

00:02.0 VGA compatible controller: Intel Corporation UHD Graphics (rev 05) DeviceName: Onboard - Video Subsystem: Micro-Star International Co., Ltd. [MSI] Device 12aa Kernel driver in use: i915
--
01:00.0 VGA compatible controller: NVIDIA Corporation TU106 [GeForce RTX 2060] (rev a1) Subsystem: Micro-Star International Co., Ltd. [MSI] Device 12aa Kernel driver in use: nvidia Kernel modules: nvidiafb, nouveau, nvidia_drm, nvidia

I have tried the following:

• Add the kernel options i915.enable_psr=0, i915.enable_dc=0

• Enable early KMS for the Intel graphics driver (add i915 to /etc/initramfs-tools/modules)

• Enable GuC with i915.enable_guc=2, however it isn't working as $ sudo cat /sys/kernel/debug/dri/0/i915_guc_load_status | grep status: returns status: DISABLED

• Change the X.Org display driver to modeset instead of the xserver-xorg-video-intel

• Update the linux kernel to 5.8

• Add the following to /usr/share/X11/xorg.conf.d/10-intel.conf

   Section "Device" Identifier "Intel Graphics" Driver "intel" Option "NoAccel" "True" Option "DRI" "False" EndSection

One observation is that when I change the Prime Profile to Performance mode (i.e. only the nvidia gpu is used and the intel one isn't) I don't get any of these errors in dmesg. However this isn't a solution for me since this options drains my battery very quickly.

I am a new Ubuntu user and I would really appreciate if someone could give a hand or just provide a workaround so I can have a stable system with no crashes. Let me know if you need any additional information. Thanks in advance!

Update 20/12/2020:

Setting GRUB_CMDLINE_LINUX="nouveau.modeset=0" on /etc/default/grub stopped the dmesg atomic update failure errors. However, now glxinfo|egrep "OpenGL renderer" gives OpenGL renderer string: llvmpipe (LLVM 10.0.0, 256 bits) instead of OpenGL renderer string: Mesa Intel(R) UHD Graphics (CML GT2). This is a problem because now I get extremely high CPU usage from gnome-shell. I don't really know what to take out from this information.

Help would be much appreciated.

In the meanwhile I have restored the grub configuration and done some other changes.$ inxi -G

Graphics: Device-1: Intel UHD Graphics driver: i915 v: kernel Device-2: NVIDIA TU106 [GeForce RTX 2060] driver: nvidia v: 450.80.02 Display: x11 server: X.Org 1.20.8 driver: modesetting,nvidia resolution: 1920x1080~144Hz OpenGL: renderer: Mesa Intel UHD Graphics (CML GT2) v: 4.6 Mesa 20.0.8

Update 21/12/2020:

Ok so I have been running my system with the Nvidia Prime performance profile on (I think this means the iGPU isn't being used, only the dGPU - nvidia - is) and I just got a freeze while listening to Spotify (which happens to also be one of the reasons why my computer has frozen in the past), however this time I didn't register any Atomic update error in this session and journalctl -b -1 -e didn't register anything relevant (at least for me). I will follow the answer to this question How can I tell why 20.04 is crashing? and then I will update the topic. Let me know if there's any output/ information you need to understand better the problem.

Update 23/12/2020:

I performed a memtest from and got 0 errors (results below):

I also did a clean install of Ubuntu, Mint and Manjaro. Every one of them would show the Atomic update error in dmesg. I sent the laptop for the repair service as I think the problem is due to hardware malfunction.

3

1 Answer

So the laptop came out from RMA and they told me there was nothing wrong with it. Unfortunately I had to switch to Windows as I can't afford having an unstable system like I described above. In the future I may try to install a newer version of Ubuntu to check if the problem persists.
