As described by the Thunderbolt 3 Technology Brief DisplayPort signals transmitted over Thunderbolt 3 links have higher priority than PCIe/USB data so in case the total required bandwidth exceeds the maximum bandwidth of 40 Gb/s the PCIe/USB bandwidth will be capped. I'm trying to understand how much bandwidth will be left for PCIe/USB data on a Thunderbolt 3 connection when daisy chaining multiple monitors. I'm using the following configuration as an example:

• UHD ("4k" 3840x2160) @ 60 Hz, 30 bit per pixel (an expensive monitor for photo editing)
• UHD ("4k" 3840x2160) @ 60 Hz, 24 bit per pixel (a regular office monitor)

What I found out so far

• According to Wikipedia Thunderbolt 3 tunnels DisplayPort 1.2, after a product refresh DisplayPort 1.4. This is important since DisplayPort 1.4 introduced Display Stream Compression. According to the datasheet of my CPU it supports only DisplayPort 1.2 (see Table 2-27). For photo editing compression might not be desired anyway.

• According to the datasheet of my CPU the bandwidth required by a DisplayPort signal with UHD resolution @ 60 Hz and 24 bit/pixel is 16.00 Gb/s (see Table 2-28). Can someone explain how to calculate this? I tried

  3840 * 2160 pixels * 24 bit/pixel * 60 Hz * (10/8) = 14.9 Gb/s

  but although I factored in the 8b/10b encoding something seems to be missing (some sort of header information?).

• Assuming that the data rate for a 30 bit/pixel signal would be 30/24 times higher and taking into account that Thunderbolt 3 uses 128b/132b encoding, the total bandwidth occupied by DisplayPort data would be 16.5 Gb/s (monitor 1) + 13.2 Gb/s (monitor 2) = 29.7 Gb/s. Assuming that Thunderbolt 3 doesn't add any additional overhead this should leave 10.8 Gb/s for PCIe data transfer (enough for a USB 3.1 link or a 10 GbE adapter). Is this assessment correct?

---

To make the answers to this questions useful for others using different hardware I would appreciate if someone could shine some light on how to calculate the required bandwidth.

1 Answer

Please see this data rate required calculator:

Reproducing the calculations below:

Data Rate Required: 16.00 Gbit/s

Video Format: 3840 × 2160 (16∶9 ratio) at 60 Hz 10 bpc (30 bit/px) RGB color Uncompressed CVT-RB timing format

Frame Size: 3,840 × 2,160 = 8,294,400 pixels per frame (8.3 Mpx)

Effective Frame Size with CVT-RB Blanking Intervals: 4,000 × 2,222 = 8,888,000 pixels per frame (8.9 Mpx)

Effective Pixel Rate: 8,888,000 px per frame × 60 frames per second = 533,280,000 pixels per second

Bit Rate: 533,280,000 px/s × 30 bit/px = 15,998,400,000 bits per second (16.00 Gbit/s)

CVT-RB Timing Formula:

Constants:

VMIN = 0.00046 seconds

HBLANK = 160 pixels

Input Variables:

H = 3,840 pixels

V = 2,160 pixels

F = 60 Hz

Formulas:

VBLANK = (V • VMIN) / (( 1⁄F ) − VMIN)

= (2,160 • 0.00046) / (( 1⁄60 ) − 0.00046)

= ( 61.3 )↑ = 62 pixels

HEFFECTIVE = H + HBLANK = 3,840 + 160 = 4,000 pixels

VEFFECTIVE = V + VBLANK = 2,160 + 62 = 2,222 pixels
