$\begingroup$

Let $D_N$ be the $N$th Dirichlet kernel, $D_N = \sum_{k = -N}^N w^k$, where $w = e^{ix}$. Define the Fejer kernel to be $F_N = \frac{1}{N}\sum_{k = 0}^{N-1}D_k$. Then $$F_N = \frac{1}{N}\frac{\sin^2(N x/2)}{\sin^2(x/2)}$$.

So far I have $D_k = \frac{w^{k+1} - w^{-k}}{w-1}$, and so $$ \begin{align*} F_N &= \frac{1}{N}\sum_{k=0}^{N-1} D_k \\ &= \frac{1}{N(w-1)}\sum_{k=0}^{N-1} (w^{k+1} - w^{-k}) \\ &= \frac{1}{N(w-1)}\left ( w\sum_{k=0}^{N-1} w^k - \sum_{k=-N+1}^0 w^k \right ) \\ &= \frac{1}{N(w-1)}\left ( \frac{w(w^N - 1)}{w-1} - \frac{1-w^{-N + 1}}{w-1} \right ) \\ &= \frac{1}{N(w-1)^2}\left ( w^{N+1} +w^{-N + 1} - (w + 1) \right ) \end{align*} $$

$\endgroup$

2 Answers

$\begingroup$

We can prove the equality for the Fejér kernel in the following way. Using the formula for the geometric progression and the fact that $e^{i\theta}-e^{-i\theta}=2i\sin\theta$ for each $\theta\in\mathbb R$, \begin{align*} D_k(x) &=e^{-ikx}\sum_{s=0}^{2k}e^{isx}\\ &=e^{-ikx}\frac{1-e^{ix(2k+1)}}{1-e^{ix}}\\ &=\frac{e^{-ix(k+1/2)}-e^{ix(k+1/2)}}{e^{-ix/2}-e^{ix/2}}\\ &=\frac{\sin(x(k+1/2))}{\sin(x/2)}. \end{align*} Using the product-to-sum identity and the power reduction formula, \begin{align*} F_n(x) &=\frac1{n\sin(x/2)}\sum_{k=0}^{n-1}\sin(x(k+1/2))\\ &=\frac1{2n\sin^2(x/2)}\sum_{k=0}^{n-1}2\sin(x(k+1/2))\sin(x/2)\\ &=\frac1{2n\sin^2(x/2)}\sum_{k=0}^{n-1}[\cos(kx)-\cos((k+1)x)]\\ &=\frac{1-\cos (nx)}{2n\sin^2(x/2)}\\ &=\frac1n\biggl[\frac{\sin(nx/2)}{\sin(x/2)}\biggr]^2. \end{align*} The trigonometric identities can be found here.

$\endgroup$ $\begingroup$

Remember that $NF_N(x)=D_0(x)+\dots+D_{N-1}(x)$ where $D_n(x)$ is the Dirichlet kernel. Therefore , if $\omega = e^{ix}$ we have$$NF_N(x)=\sum_{n=0}^{N-1}\frac{\omega^{-n}-\omega^{n+1}}{1-\omega}$$Then we have $$\sum_{n=0}^{N-1}\omega^{-n}=1+1/\omega+\dots+1/\omega^{N-1}=\frac{1-\omega^{-N}}{1-\omega^{-1}}=\omega\frac{\omega^{-N}-1}{1-\omega}$$and $$\sum_{n=0}^{N-1}\omega^{n+1}=\omega(1+\omega+\dots+\omega^{N-1})=\omega\frac{1-\omega^N}{1-\omega}$$Thus $$NF_N(x)=\frac{\sum_{n=0}^{N-1}\omega^{-n}-\sum_{n=0}^{N-1}\omega^{n+1}}{1-\omega} =\omega\frac{\omega^N-2+\omega^{-N}}{(1-\omega)^2}=\frac{(\omega^{N/2}-\omega^{-N/2})^2}{(\omega^{1/2}-\omega^{-1/2})^2}=\frac{\sin^2(Nx/2)}{\sin^2(x/2)}$$So have get$$F_N(x)=\frac{1}{N}\frac{\sin^2(Nx/2)}{\sin^2(x/2)}$$

$\endgroup$
