I am trying to setup a RabbitMQ tasks queue in a kubernetes cluster and need to be able to populate the task queue from outside of the kubernetes cluster. I am trying to accomplish this using the nginx ingress controller. I am running into errors when trying to declare a queue or send messages to an existing queue from outside of the cluster. Using the amqp-tools cli in Ubuntu from outside the cluster I get an error:

$ export BROKER_URL=amqp://<host-name>:80/rabbitmq
$ /usr/bin/amqp-declare-queue --url=$BROKER_URL -q foo -d
logging in to AMQP server: invalid AMQP data

If I do this same thing from a VM inside the cluster, I can create and send message to the queue just fine. I am also able to connect to the RabbitMQ management UI from outside of the cluster but if I try to declare a queue from the UI I get the error Management API returned status code 405 - displayed at the bottom of the screen.

I was reading that the virtual host in RabbitMQ '/' has problems with nginx because of how it parses the host but I am not very experienced with this sort of thing and dont know how to fix that.

Any help with this would be greatly appreciated.

I am deploying the nginx ingress controller with the recommended manifest:

kubectl apply -f

RabbitMQ is deployed with this manifest:

---
apiVersion: v1
kind: Namespace
metadata: name: rabbitmq labels: app: rabbitmq
---
apiVersion: v1
kind: Service
metadata: name: rabbitmq-service namespace: rabbitmq labels: component: rabbitmq
spec: type: ClusterIP ports: - name: amqp port: 5672 targetPort: 5672 protocol: TCP - name: http port: 80 targetPort: 15672 protocol: TCP selector: app: taskQueue component: rabbitmq
---
apiVersion: extensions/v1beta1
kind: Ingress
metadata: name: rabbit-ingress namespace: rabbitmq annotations: /$1 "false"
spec: rules: - host: <host-name> http: paths: - path: /rabbitmq/?(.*) backend: serviceName: rabbitmq-service servicePort: 5672
---
apiVersion: extensions/v1beta1
kind: Ingress
metadata: name: rabbit-manage-ingress namespace: rabbitmq annotations: /$1 "false"
spec: rules: - host: <host-name> http: paths: - path: /rabbitmq-manage/?(.*) backend: serviceName: rabbitmq-service servicePort: 80
---
apiVersion: v1
kind: ReplicationController
metadata: labels: app: taskQueue component: rabbitmq name: rabbitmq-controller namespace: rabbitmq
spec: replicas: 1 template: metadata: labels: app: taskQueue component: rabbitmq spec: containers: - image: rabbitmq:3-management name: rabbitmq ports: - containerPort: 5672 - containerPort: 15672 resources: limits: cpu: 100m

2

1 Answer

As far as i know, RabbitMQ does not provide a HTTP-API for interacting (at least it's not the default). NGINX-Ingress cannot use an Ingress resource to expose anything different to a HTTP-Service. Take a look at the documentation to learn how to expose a TCP- or UDP-Based service.
