I would like to reproduce the plot immediately below by using ggplot2. I can come close, but cannot remove the top and right borders. Below I present several attempts using ggplot2, including several suggestions found on or via Stackoverflow. Unfortunately I have not been able to get those suggestions to work.

I am hoping someone may be able to correct one or more of the code snippets below.

Thank you for any suggestions.

# desired plot
a <- seq(1,20)
b <- a^0.25
plot(a,b, bty = "l")
library(ggplot2)
df <- as.data.frame(cbind(a,b))
# 1. ggplot2 default
ggplot(df, aes(x = a, y = b)) + geom_point()
# 2. removes background color
ggplot(df, aes(x = a, y = b)) + geom_point() + opts(panel.background = theme_rect(fill='white', colour='black'))
# 3. also removes gridlines
none <- theme_blank()
ggplot(df, aes(x = a, y = b)) + geom_point() + opts(panel.background = theme_rect(fill='white', colour='black')) + opts(panel.grid.major = none, panel.grid.minor = none)
# 4. does not remove top and right border
ggplot(df, aes(x = a, y = b)) + geom_point() + opts(panel.background = theme_rect(fill='white', colour='black')) + opts(panel.grid.major = none, panel.grid.minor = none) + opts(panel.border = none)
# 5. does not remove top and right border
ggplot(df, aes(x = a, y = b)) + geom_point() + opts(panel.background = theme_rect(fill='white', colour='black')) + opts(panel.grid.major = none, panel.grid.minor = none) + opts(axis.line = theme_segment())
# 6. removes x and y axis in addition to top and right border
#
ggplot(df, aes(x = a, y = b)) + geom_point() + opts(panel.background = theme_rect(fill='white', colour='black')) + opts(panel.grid.major = none, panel.grid.minor = none) + opts(panel.background=theme_rect(colour=NA))
# 7. returns error when attempting to remove top and right border
#
#
# Error in el(...) : could not find function "polylineGrob"
#
theme_L_border <- function(colour = "black", size = 1, linetype = 1) { structure( function(x = 0, y = 0, width = 1, height = 1, ...) { polylineGrob( x=c(x+width, x, x), y=c(y,y,y+height), ..., default.units = "npc", gp=gpar(lwd=size, col=colour, lty=linetype), ) }, class = "theme", type = "box", call = match.call() )
}
ggplot(df, aes(x = a, y = b)) + geom_point() + opts(panel.background = theme_rect(fill='white', colour='black')) + opts(panel.grid.major = none, panel.grid.minor = none) + opts( panel.border = theme_L_border())

1

7 Answers

EDIT Ignore this answer. There are now better answers. See the comments. Use + theme_classic()

EDIT

This is a better version. The bug mentioned below in the original post remains (I think). But the axis line is drawn under the panel. Therefore, remove both the panel.border and panel.background to see the axis lines.

library(ggplot2)
a <- seq(1,20)
b <- a^0.25
df <- data.frame(a,b)
ggplot(df, aes(x = a, y = b)) + geom_point() + theme_bw() + theme(axis.line = element_line(colour = "black"), panel.grid.major = element_blank(), panel.grid.minor = element_blank(), panel.border = element_blank(), panel.background = element_blank())

Original postThis gets close. There was a bug with axis.line not working on the y-axis (see here), that appears not to be fixed yet. Therefore, after removing the panel border, the y-axis has to be drawn in separately using geom_vline.

library(ggplot2)
library(grid)
a <- seq(1,20)
b <- a^0.25
df <- data.frame(a,b)
p = ggplot(df, aes(x = a, y = b)) + geom_point() + scale_y_continuous(expand = c(0,0)) + scale_x_continuous(expand = c(0,0)) + theme_bw() + opts(axis.line = theme_segment(colour = "black"), panel.grid.major = theme_blank(), panel.grid.minor = theme_blank(), panel.border = theme_blank()) + geom_vline(xintercept = 0)
p

The extreme points are clipped, but the clipping can be undone using code by baptiste.

gt <- ggplot_gtable(ggplot_build(p))
gt$layout$clip[gt$layout$name=="panel"] <- "off"
grid.draw(gt)

Or use limits to move the boundaries of the panel.

ggplot(df, aes(x = a, y = b)) + geom_point() + xlim(0,22) + ylim(.95, 2.1) + scale_x_continuous(expand = c(0,0), limits = c(0,22)) + scale_y_continuous(expand = c(0,0), limits = c(.95, 2.2)) + theme_bw() + opts(axis.line = theme_segment(colour = "black"), panel.grid.major = theme_blank(), panel.grid.minor = theme_blank(), panel.border = theme_blank()) + geom_vline(xintercept = 0)

0

Recent updates to ggplot (0.9.2+) have overhauled the syntax for themes. Most notably, opts() is now deprecated, having been replaced by theme(). Sandy's answer will still (as of Jan '12) generates a chart, but causes R to throw a bunch of warnings.

Here's updated code reflecting current ggplot syntax:

library(ggplot2)
a <- seq(1,20)
b <- a^0.25
df <- as.data.frame(cbind(a,b))
#base ggplot object
p <- ggplot(df, aes(x = a, y = b))
p + #plots the points geom_point() + #theme with white background theme_bw() + #eliminates background, gridlines, and chart border theme( plot.background = element_blank(), panel.grid.major = element_blank(), panel.grid.minor = element_blank(), panel.border = element_blank() ) + #draws x and y axis line theme(axis.line = element_line(color = 'black'))

generates:

2

An alternative to theme_classic() is the theme that comes with the cowplot package, theme_cowplot() (loaded automatically with the package). It looks similar to theme_classic(), with a few subtle differences. Most importantly, the default label sizes are larger, so the resulting figures can be used in publications without further modifications needed (in particular if you save them with save_plot() instead of ggsave()). Also, the background is transparent, not white, which may be useful if you want to edit the figure in illustrator. Finally, faceted plots look better, in my opinion.

Example:

library(cowplot)
a <- seq(1,20)
b <- a^0.25
df <- as.data.frame(cbind(a,b))
p <- ggplot(df, aes(x = a, y = b)) + geom_point()
save_plot('plot.png', p) # alternative to ggsave, with default settings that work well with the theme

This is what the file plot.png produced by this code looks like:

Disclaimer: I'm the package author.

I followed Andrew's answer, but I also had to follow and set the x and y axes separately due to a bug in my version of ggplot (v2.1.0).

Instead of

theme(axis.line = element_line(color = 'black'))

I used

theme(axis.line.x = element_line(color="black", size = 2), axis.line.y = element_line(color="black", size = 2))

0

The above options do not work for maps created with sf and geom_sf(). Hence, I want to add the relevant ndiscr parameter here. This will create a nice clean map showing only the features.

library(sf)
library(ggplot2)
ggplot() + geom_sf(data = some_shp) + theme_minimal() + # white background theme(axis.text = element_blank(), # remove geographic coordinates axis.ticks = element_blank()) + # remove ticks coord_sf(ndiscr = 0) # remove grid in the background

0

Simplification from the above Andrew's answer leads to this key theme to generate the half border.

theme (panel.border = element_blank(), axis.line = element_line(color='black'))

Here's an extremely simple answer

yourPlot + theme( panel.border = element_blank(), panel.grid.major = element_blank(), panel.grid.minor = element_blank(), axis.line = element_line(colour = "black") )

It's that easy. Source: the end of this article
