our lab's RAID0 array has seemingly stopped working. The system knows there are drives there, but I haven't been able to assemble them no matter what I try googling around in these forums. I've provided below some of the basic things that seem to get asked, but can provide more. I'm not super well-versed in the particulars of technical computer things, but I can follow commands pretty well.

~$ sudo mdadm --detail /dev/md0
mdadm: Unknown keyword /dev/md0:
/dev/md0: Version : 1.2 Raid Level : raid0 Total Devices : 13
Persistence : Superblock is persistent State : inactive Name : mhara-BlackServer:0 (local to host mhara-BlackServer) UUID : 5643be60:fe02d346:c038cc99:393231f9 Events : 20279
Number Major Minor RaidDevice - 8 64 - /dev/sde - 8 208 - /dev/sdn - 8 32 - /dev/sdc - 8 176 - /dev/sdl - 8 144 - /dev/sdj - 8 112 - /dev/sdh - 8 80 - /dev/sdf - 8 224 - /dev/sdo - 8 48 - /dev/sdd - 8 192 - /dev/sdm - 8 160 - /dev/sdk - 8 128 - /dev/sdi - 8 96 - /dev/sdg

and

~$ sudo cat /proc/mdstat
Personalities : [linear] [multipath] [raid0] [raid1] [raid6] [raid5] [raid4] [raid10]
md0 : inactive sdj[8](S) sdk[9](S) sdo[13](S) sdn[12](S) sdi[10](S) sdl[7](S) sdm[11](S) sdc[0](S) sdg[5](S) sdd[2](S) sdh[6](S) sde[3](S) sdf[4](S) 50789537656 blocks super 1.2

unused devices:

One thing that I've noticed is there seems to be some confusion between whether the array is /dev/md0 or /dev/md/0

e.g.

~$ sudo mdadm -E --scan
mdadm: Unknown keyword /dev/md0:
ARRAY /dev/md/0 metadata=1.2 UUID=5643be60:fe02d346:c038cc99:393231f9 name=mhara-BlackServer:0 spares=1

Any help is appreciated. I want to get this thing up and running, hopefully with data intact, for the lab.

Edit 1:

content of mdadm.conf:
# mdadm.conf
#
# Please refer to mdadm.conf(5) for information about this file.
#
# by default (built-in), scan all partitions (/proc/partitions) and all
# containers for MD superblocks. alternatively, specify devices to scan, using
# wildcards if desired.
#DEVICE partitions containers
# auto-create devices with Debian standard permissions
CREATE owner=root group=disk mode=0660 auto=yes
# automatically tag new arrays as belonging to the local system
HOMEHOST <system>
# instruct the monitoring daemon where to send mail alerts
MAILADDR root
# definitions of existing MD arrays
# This file was auto-generated on Tue, 11 Apr 2017 15:31:46 -0500
# by mkconf $Id$
ARRAY /dev/md0 UUID=5643be60:fe02d346:c038cc99:393231f9
/dev/md0: Version : 1.2 Raid Level : raid0 Total Devices : 13
Persistence : Superblock is persistent State : inactive Name : mhara-BlackServer:0 (local to host mhara-BlackServer) UUID : 5643be60:fe02d346:c038cc99:393231f9 Events : 20279
Number Major Minor RaidDevice - 8 64 - /dev/sde - 8 208 - /dev/sdn - 8 32 - /dev/sdc - 8 176 - /dev/sdl - 8 144 - /dev/sdj - 8 112 - /dev/sdh - 8 80 - /dev/sdf - 8 48 - /dev/sdd - 8 192 - /dev/sdm - 8 16 - /dev/sdb - 8 160 - /dev/sdk - 8 128 - /dev/sdi - 8 96 - /dev/sdg

I previously had the output of mdadm -E --scan appended onto the end of the .conf file, but in trying to assemble it I had an error that there were two arrays named md0 or something like that, so I removed it.

Edit 2:

I just found out--from someone who knows a bit more about this than me, but who is not available to actually help--that the RAID was not setup with mdadm, and was probably setup as a hardware RAID(?). Any thoughts about how to determine how this was setup through the terminal? Any ideas where I should start? My googling thus far has been far less fruitful. Below is the sum of the info I have so far:

It's a full RAID 6, meaning that you're using 12 disks actively and you have 2 remaining disks to swap in incase one of the other disks break The two swap disks were the last disks in the array, 12, and 13 But I would have to physicially look at the computer or the notes to figure out exactly which one is which
