i want to connect two soft phone using asterisk after configuration the sip.conf and iax.conf and extension.conf can't enter any order from cli example of the error:

Connected to Asterisk 11.6-cert1 currently running on fedo-VirtualBox
(pid = 1066)
fedo-VirtualBox*CLI> sip show peers
No such command 'sip show peers' (type 'core show help sip show' for
other possible commands)

4

3 Answers

module show like sip

is returning something?

if not do this

module load chan_sip.so

and try again

0

I tried the above answer and it still failed. Reason was: chan_sip.so was not there in modules folder.

So, I uninstalled the asterisk

make uninstall

Then I started installing the asterisk-13 again

./configure
make menuconfig

In menu select, go to channel drivers option and check the checkbox chan_sip [Probably unchecked]. Then, do the below command

make & make install & make config

In my case i have installed asterisk through yum so recompiling will not work for me so i search yum repo for chan_sip.so

[root@MTL-189551 asterisk]# yum whatprovides */chan_sip.so

Note it is very necessary to install the correct version of the module i have installed Asterisk 13.17.2 so it is very necessary to install same module

In yum search result i found this version

asterisk-sip-13.17.2-vici.el7.centos.x86_64 : Legacy SIP channel driver for
Asterisk
Repo : goautodial-updates
Matched from:
Filename : /usr/lib64/asterisk/modules/chan_sip.so
[root@MTL-189551 asterisk]# yum install asterisk-sip-13.17.2

Before restart asterisk add below line

[root@MTL-189551 ~]# vim /etc/asterisk/modules.conf
Find the below line in file and uncomment or add
require = chan_sip.so

After this restart your asterisk and connect to asterisk console and check whether module is loaded or not

 MTL-189551*CLI> module show like chan_sip.so
Module Description Use Count Status Support Level
chan_sip.so Session Initiation Protocol (SIP) 0 Running core
1 modules loaded
MTL-189551*CLI>
