Task:

• I would like to show a really big DataTable in UI which is horizontally and vertically is scrollable

Issue:

• Cannot set scrolling on X axis
• UI cuts/hides down the first half of the table if not zooming out
• Makes the UI not usaböe

Tried:

• Reading and setting the following properties
• Reading and setting custom styles with the help of git documents
• Reading and setting extra HTML tags like and styles allowing overflowX to make it scrollable

Details:

• Table is roughly 50-60 columns
• 200+ rows
• component: React-Data-Table-Component
• component uses custom solution using a lot of div tags (this is out of the box upon inspecting the react-data-table-component in website)

Needs solution:

• Cannot scroll left and right in table
• Cannot see left part of the table

Example Column:

 { name: 'header1', id: 'header1', maxWidth: 'auto', minWidth: 'auto', selector: row => row.data1, sortable: true, compact: true,
},

Example Table:

<div style={{ overflowX: "visible", scrollSnapAlign: "start" }}> <DataTable columns={DataTableHeaders} data={filteredItems} pagination paginationComponentOptions={paginationComponentOptions} selectableRows defaultSortField="name" subHeader subHeaderComponent={subHeaderComponent} subHeaderAlign={Alignment.CENTER} expandableRows expandableRowsComponent={ExpandedComponent} dense highlightOnHover fixedHeader persistTableHead responsive direction={Direction.LTR} //customStyles={customStyles} //theme="dark" //className={styleDataTable.rdt_TableRow} /> </div>

1 Answer

Apparently this issue can be solved by setting fixed % width based on viewable area

 <div style={{ overflowX: "hidden", width: "94vw", alignItems: "flex-start" }}> <DataTable className={styleDataTable.rdt_TableCol} columns={DataTableHeaders} data={filteredItems} pagination paginationComponentOptions={paginationComponentOptions} defaultSortField="name" subHeader subHeaderComponent={subHeaderComponent} subHeaderAlign={Alignment.LEFT} expandableRows expandableRowsComponent={ExpandedComponent} dense highlightOnHover fixedHeader persistTableHead responsive direction={Direction.LTR} //customStyles={customStyles} //theme="dark" //className={styleDataTable.rdt_TableRow} /> </div>

Notice that width: 94vw which will make the table fit on the 94% of the visible area. This way it becomes scrollable from left to right and the data table wont overflow and wont disappear.

Not sure if there is a better solution but for now this works alright.
