I recently purchased a GTX 970 for my system and all seemed to be fine, drivers install perfectly, games run OK if not a little under what I would have expected (this is probably due to my CPU not being up to par for those games but still) until I checked my GPU-Z reading and noticed my card is always running at PCI-E 1.1 x16 instead of 2.0 as my motherboard allows:

My motherboard: Asus M4N68T-M V2

No idea what could be causing this aside from improper placement of the GPU in the PCIe slot, tried that once already, could be worth another try but I'd like some feedback from you lovely people first.

2

2 Answers

It doesn't look like the motherboard's chipset supports PCIe 2.0 - for example, the Wikipedia entry for the nForce 630a states 20 lanes of PCIe 1.1.

Edit More information: running at PCIe 1.1 x16 is probably not something to worry about, Guru3D just did an article on it: PCI Express Scaling Game Performance Analysis review which concludes "if you use a single high-end graphics card then really, even the PCIe Gen 1.1 slot would be sufficient. Gen 2.0 is preferred and Gen 3.0 only brings in a marginal improvement."

1

no. it is win 7 thing. my friend have 750 gtx that work same as yours in 1.1 mode even on full load. and he have win 7 when he got card to my pc and I use win 10,GPU-Z show me that his card work on 2.0 on full load. So,win 7 is a problem.when win 7 was made there was no 3.0 PCI-E ports or cards and he become confused and put card in power save mode for security because his architecture was not made to run or put 3.0 cards to downgrade position into 2.0 mode but he run to basics and put them in 1.1. Test card in win 10 and you will see that it will detect her as 2.0 in old socket 775 or 3.0 on newer MB's

1
