Dealing with a weired issue where netplan is not detecting the uplink going down for one of it's primary slave and not selecting the other slave. I also tried setting up all parameters of mii-monitor-interval but that doesn't seems to be working either.

root@core2:~# lsb_release -a

No LSB modules are available.

Distributor ID: Ubuntu

Description: Ubuntu 18.04.4 LTS

Release: 18.04

Codename: bionic

root@core2:~# uname -a

Linux core2 4.15.0-121-generic #123-Ubuntu SMP Mon Oct 5 16:16:40 UTC 2020 x86_64 x86_64 x86_64 GNU/Linux

root@core2:~# dpkg -l | grep netplan

ii netplan.io0.98-0ubuntu1~18.04.1 amd64 YAML network configuration abstraction for various backends

root@core2:~#

Config file ->

network:
version: 2
renderer: networkd
ethernets:
enp6s0f0:
dhcp4: no
enp6s0f1:
dhcp4: no
bonds:
bond0:
addresses:
- 10.10.10.250/24
gateway4: 10.10.10.1
nameservers:
addresses: [8.8.8.8]
interfaces:
- enp6s0f0
- enp6s0f1
parameters:
mode: active-backup
primary: enp6s0f0
mii-monitor-interval: 10s
min-links: 1
down-delay: 50

Interesting issue is that event after setting mii-monitor-interval value to 10s, it's not updating on bond interface. It's shows 0ms and that means netplan is not monitoring the mii uplink.

root@core2:~# cat /proc/net/bonding/bond0

Ethernet Channel Bonding Driver: v3.7.1 (April 27, 2011)

Bonding Mode: fault-tolerance (active-backup)

Primary Slave: enp6s0f0 (primary_reselect always)

Currently Active Slave: enp6s0f0

MII Status: up

MII Polling Interval (ms): 0

Up Delay (ms): 0

Down Delay (ms): 0

Slave Interface: enp6s0f1

MII Status: up

Speed: 1000 Mbps

Duplex: full

Link Failure Count: 0

Permanent HW addr: 00:1b:21:3e:3f:29

Slave queue ID: 0

Slave Interface: enp6s0f0

MII Status: up

Speed: 1000 Mbps

Duplex: full

Link Failure Count: 0

Permanent HW addr: 00:1b:21:3e:3f:28

Slave queue ID: 0

root@core2:~#

Any help will be really appreciated.

Thank you

4

1 Answer

Edit 3

I had the same problem with ubuntu 20.04.

I could change the primary device of the bond but if I disconnect the nic's cable no failover routing happens.

MIIMonitorSec is properly set up in /run/systemd/network

Ah, after a full reboot and carefully restarting a ping probe it started to work.

Here is my configuration:

 network: version: 2 renderer: networkd ethernets: eno1: addresses: [] dhcp4: false dhcp6: false eno2: addresses: [] dhcp4: false dhcp6: false bonds: bond0: dhcp4: no interfaces: [eno2, eno1] parameters: mode: active-backup primary: eno1 mii-monitor-interval: 200 bridges: br0: interfaces: [bond0] dhcp4: false dhcp6: false addresses: [192.168.1.2/24] gateway4: 192.168.1.1 nameservers: addresses: [192.168.1.1]

test case1:

i. ping foo.bar ii. (remove cable from primary bonding nic)

ping get stucks

iii. CTRL-C (abort ping)

iv. ping foo.bar # restart ping probe

Expect:

ping foo.bar
0.2 ms success
(..)
NIC Copper is down
package loss
ping foo.bar
0.2 ms success
