MMC Snap-in will not load most processes and throws an error on Windows 2008R2 x64. It gives the error:

mmc could not create the snap-in. CLSID: FX:{18ea3f92-d6aa-41d9-a205-2023400c8fbb} when opening server manager.

It also gives similar errors opening the event viewer, etc. I think that the .NET Framework is messed up but I can't narrow down the exact cause. Has anyone else seen this issue? I have a dmp file of mmc.exe but haven't been able to get anything meaningful out of it.

7 Answers

I know this is an old post, but I ran into the same issue and tried everything I could find on the internet regarding this. After working with Microsoft for 3 days we found the fix. Please see below for all the steps that were completed, and finally what solved the issue. This was for a Server 2008R2 machine:

Symptoms

MMC could not create the snap-in. The snap-in might not have been installed correctly.

Name: Server Manager

CLSID: FX:{18ea3f92-d6aa-41d9-a205-2023400c8fbb}

Name: Event Viewer

clsid: fx: {b05566ad-fe9c-4363-be05-7a4cbb7cb510} Event Viewer

Name: Task Scheduler

clsid: fx: {c7b8fb06-bfe1-4c2e-9217-7a69a95bbac4} Task Scheduler

Name: Windows Firewall with Advanced Security

clsid: fx: {b05566ac-fe9c-4368-be02-7a4cbb7cbe11} Windows Firewall with Advanced Security

Server Information

Microsoft Server 2008R2 SP1

HP ProLiant DL380G6

Resolution

• Replaced C:\Windows\Microsoft.NET\Framework64\v2.0.50727\CONFIG\machine.config with known working file

• Replaced entire C:\Windows\Microsoft.NET\Framework64\v2.0.50727\CONFIG\ folder with known working folder

• Ran System Update Readiness Tool for Server 2008 – all reports came back with no error

• Ran c:\Windows\Microsoft.NET\Framework\v3.5\WFServicesReg.exe /r /b

• sfc /scannow was ran, came back clean

• Ran .NET Verifier on all version of .NET, all came back verified successfully

• Reinstalled .NET 3.5 via CLI:

  DISM /online /disable-feature /FeatureName:NetFx3
  DISM /online /enable-feature /FeatureName:NetFx3

• Removed registry keys:

  HKLM\Software\Microsft\OLE\MachineAccessRestriction HKLM\Software\Microsft\OLE\MachineLaunchRestriction

• Restarted “Start DCOM Server Process Launcher” service

• Replaced files dsadmin.dll and dssite.msc located at C:\Windows\winsxs\x86_microsoft-windows-d..mc-sitesandservices_31bf3856ad364e35_6.1.7601.17514_none_a143f244c78549c1 with a good know version

• HKEY_LOCAL_MACHINE\SOFTWARE\Microsoft\MMCSnapIns\FX{b05566ad-fe9c-4363-be05-7a4cbb7cb510}\RuntimeVersion, changing value from v2.0.40607 to v2.0.50727

Final resolution from Microsoft:

• The Servicing stack of the Operating System was clean as reported by the Sfc output
• Uninstalling/Reinstlaling Visual C++ 2005/2008/2010 with a reboot took out of the picture Visual C++ library components
• The .Net Policy had the correct value under HKEY_LOCAL_MACHINE\SOFTWARE\Microsoft\.NETFramework\Policy\v2.0 - 50727=50727-50727
• Uninstalling McAfee didn’t help even after a reboot.

• The Components and Schema hive unloaded after a few reboots

• The IDNA trace that we gathered indicated that we fail due to a bad function pointer most probably returned by a .net component. After applying the Update and a reboot the issue went away which indicates we have a broken/damaged .net component on the server.

Check out this thread. It sounds like a corrupted update.

3

I was having same issue, but it worked just fine, when i removed .Net 3.5 from my system, and just by that removal everything got back to normal .. this looked to be a problem with .net itself, i have not tried to install 3.5 again when i will do that will update the thread

1

Look for the corrupted snapin and remove the key after backup

Example for Task scheduler

[HKEY_LOCAL_MACHINE\SOFTWARE\Microsoft\MMC\SnapIns\FX:{c7b8fb06-bfe1-4c2e-9217-7a69a95bbac4}] and [HKEY_LOCAL_MACHINE\SOFTWARE\Microsoft\MMC\SnapIns\FX:{c7b8fb07-bfe1-4c2e-9217-7a69a95bbac4}]

Per Akira Umehara's answer on this thread, another solution is:

1. Navigate to the following directory on the corrupt machine: C:\Windows\Microsoft.NET\Framework64\v2.0.50727\CONFIG
2. Copy the machine.config file to desktop just in case before you go to 3rd step.
3. Rename machine.config to machine.config.old (in the original directory: C:\Windows\Microsoft.NET\Framework64\v2.0.50727\CONFIG).
4. Reboot (not always required, but ensures a clean start).

NB: The above applies to x64 operating systems. For x86, do the same only using the directory: C:\Windows\Microsoft.NET\Framework\v2.0.50727\CONFIG\.

I get the impression this only works for OSes not yet upgraded to .net framework 4 was released; though have found nothing explicitly to confirm this.

Noticing Issue and Initial Findings

I had the same issue on Windows Server 2008 R2; I believe caused by a failed Windows Update attempt; failing due to a full C drive.

• Freed up space on C drive
• Tried all techniques mentioned on here and in this blog, with no joy (mentioning as these may have partially resolved the issue).
• Noticed that the .Net Verification Tool crashed when run on .net versions =v4.
• Noticed that c:\windows\assembly was displaying sub-folders instead of the standard GAC view (potentially due to a missing desktop.ini, though I did not realise at the time)
• Noticed that some apps were reporting a missing dll (Microsoft.VisualStudio.OLE.Interop).

Steps to fix

• Ran Windows Explorer as Admin
• Copied the GAC (c:\windows\assembly) from a the VM from which this server had originally been cloned, ensuring missing files were created in the GAC, but existing content was left unimpacted (I generally wouldn't recommend this; but the server was not vital, and all other routes had been exhausted). NB: The source VM included the missing Microsoft.VisualStudio.OLE.Interop DLL.
• Rebooted

This resolved several issues:

• The GAC now displayed as expected
• The missing DLL issue was resolved (i.e. the DLL was there; and we no longer saw exceptions related to this DLL)
• The .Net Verifier ran for all versions of .net; and reported all as healthy.

However, the original issue (per question) remained.

• Reran the below commands to again remove and re-add the .net 3.5 feature:

  DISM /online /disable-feature /FeatureName:NetFx3
  DISM /online /enable-feature /FeatureName:NetFx3

• The disable command failed; but enable completed successfully

• The issue was resolved; presumably the enable-feature command somehow kicked something missed by the GAC copy into place...

I had the same error a few minutes ago on one of five identically installed, and I just updated Windows Server 2008 R2 Terminal Servers and now it works again.

All I did was go to File > Options and then I deleted the about 460 KB of files stored in the user profile, confirmed the dialog, closed the MMC. After reopening, everything is working fine again.
