I want to left align a block of equations. The equations in the block itself are aligned, but that's not related at all to my question! I want to left align the equations rather than have them centered all the time, because it looks dumb with narrow centered equations.

Example, I want to left align this

\begin{align*} |\vec a| &= \sqrt{3^{2}+1^{2}} = \sqrt{10} \\ |\vec b| &= \sqrt{1^{2}+23^{2}} = \sqrt{530} \\ \cos v &= \frac{26}{\sqrt{10} \cdot \sqrt{530}} \\ v &= \cos^{-1} \left(\frac{26}{\sqrt{10} \cdot \sqrt{530}}\right) \\ v &= \uuline{69.08...\degree}
\end{align*}

but also this

\begin{align*} f(x) = -1.25x^{2} + 1.5x
\end{align*}

How is this done? If it's even possible.

4 Answers

Try to use the fleqn document class option.

\documentclass[fleqn]{article}

(See also for a list of other options.)

You can use \begin{flalign}, like the example bellow:

\begin{flalign} &f(x) = -1.25x^{2} + 1.5x&
\end{flalign}

3

Try this:

\begin{flalign*} &|\vec a| = \sqrt{3^{2}+1^{2}} = \sqrt{10} & \\ &|\vec b| = \sqrt{1^{2}+23^{2}} = \sqrt{530} &\\ &\cos v = \frac{26}{\sqrt{10} \cdot \sqrt{530}} &\\ &v = \cos^{-1} \left(\frac{26}{\sqrt{10} \cdot \sqrt{530}}\right) &\\
\end{flalign*}

The & sign separates two columns, so an & at the beginning of a line means that the line starts with a blank column.

The fleqn option in the document class will apply left aligning setting in all equations of the document. You can instead use \begin{flalign}. This will align only the desired equations.

1
