I currently have a script that adds rules to the firewall table based on a selection criterion between two files.

FILE 1 keys.txt

<string>
<string>
..
..

FILE 2 hellos.txt

<string> <ipaddress> <ipaddress>
<string> <ipaddress> <ipaddress>
..
..

My script matches a string from file 2 with a string from file 1. If a match exists, then it adds the firewall rule for the ipaddress following the string match.

The script is as follows -

#!/bin/bash
while true
do
#Match a string from both the files and print the ipaddress to a file
word=$(awk 'FNR==NR{a[$1];next}($1 in a){print}' keys.txt hellos.txt | awk -v OFS=' ' '{ print $2, $3 }') >address.txt
#Remove duplicates for the ipaddress file
awk '!a[$0]++' address.txt > address_improved.txt
#Add firewall rule from new file.
filename=address_improved.txt
while read -r a b
do "/sbin/iptables" -I FORWARD 1 -m physdev --physdev-is-bridged --physdev-in enxa0cec80f92bd --physdev-out eno1 -s $a -d $b -j ACCEPT
done < "$filename"
sleep 0.01
#Run while loop again because the files are changing constantly
done

How can I improve this script such that I do not add duplicate firewall rules everytime the while loop executes. I tried to add the -C (check) option but it does not work for me. I just get a bad rule output.

3

1 Answer

Match a string from both the files and print the ipaddress to a file

Instead execute: (after following instructions)

ipset add allowed_hosts <ip> <ip>

(will not allow duplicates automatically)

Sets up ipset to be ready: (adjust maxelem to your liking)

ipset create allowed_hosts hash:net,net family inet hashsize 262144 maxelem 333000 counters comment

Your new rule:

 "/sbin/iptables" -I INPUT 1 -m conntrack -j ACCEPT --ctstate RELATED,ESTABLISHED "/sbin/iptables" -I INPUT 2 -m physdev --physdev-is-bridged --physdev-in enxa0cec80f92bd --physdev-out eno1 -m set --match-set allowed_hosts src,dst -j ACCEPT "/sbin/iptables" -I INPUT 3 -m physdev --physdev-is-bridged --physdev-in enxa0cec80f92bd --physdev-out eno1 -m u32 --u32 "0>>22&0x3C@ 12>>26&0x3C@ 0 & 0xFF000000=0x17000000" -j DROP "/sbin/iptables" -I FORWARD 1 -m conntrack -j ACCEPT --ctstate RELATED,ESTABLISHED "/sbin/iptables" -I FORWARD 2 -m physdev --physdev-is-bridged --physdev-in enxa0cec80f92bd --physdev-out eno1 -m set --match-set allowed_hosts src,dst -j ACCEPT "/sbin/iptables" -I FORWARD 3 -m physdev --physdev-is-bridged --physdev-in enxa0cec80f92bd --physdev-out eno1 -m u32 --u32 "0>>22&0x3C@ 12>>26&0x3C@ 0 & 0xFF000000=0x17000000" -j DROP

Now your new loop:

while read -r a b
do "/sbin/ipset" -! add allowed_hosts $a,$b
done < "$filename"

If you ever need to save the ipset table say for a reboot.

ipset save >ipset.txt

or

ipset save -f ipset.txt

bulk import, including autocreate from save.

ipset restore -f ipset.txt

It will be way more efficient as you don't need to keep changing iptables.

this single line might do away with everything but the loop

word=$(awk 'FNR==NR{a[$1];next}($1 in a){print}' keys.txt hellos.txt | awk -v OFS=' ' '{ print $2,$3 }') |xargs -n1 ipset -! add allowed_hosts

The xargs -n1 repeats the command for each line from stdin. the -! hide the duplicate entries alert. The output from the stdin is automatically appended so it isn't mentioned.

You will still need 1 iptables entry and the ipset mentioned above.
