Consider I have three computers

1. home my computer at home
2. work my computer at work
3. server my server

I can't connect from home to work using ssh because of my company firewall. But I can ssh any computer from work. For example I can ssh the server computer from work. What I wan't to do is to connect to Internet using the work connection (I want to access localhost of the work computer). I read from some toturial that I can do:

woork:~# ssh -D 4096 server

But this only allow me to connect to the Internet using the server. I want to do the inverse of this but I can't access work from server.

The final result is to open firefox at home and browse to localhost of work.

What's the solution for my case?

7

2 Answers

If you can set up an outgoing ssh connection, then you can probably set up a reverse tunnel to get back in (I'm not aware of there being a way for IT to forbid this, but you never know).

work:~# ssh -fN -R 2222:localhost:22 server

Then on the server you can do this:

server:~# ssh -p2222 localhost

And you will magically be connected back to the SSH server port on you work machine. By default the port 2222 is bound to the "localhost" address only, so connect requests from home will not work:

home:~# ssh -p2222 server ;# this will not work

Instead, you can do this:

home:~# ssh server
server:~# ssh -p2222 localhost

or both in one command like this:

home:~# ssh -o ProxyCommand="ssh -W localhost:2222" server

To make all this easier to live with, add this to your .ssh/config at home:

Host work ProxyCommand ssh -W localhost:2222 HostName server

... and now:

home:~# ssh work

... will just do the right thing.

It is possible to create the reverse tunnel bind so that the proxy business is not necessary, but then every hacker in the world will also pound on your tunnel (thinking port 2222 is non-standard and therefore safe is naive). The failed access attempts will show up in the logs on "work", IT will find out, and you'll get fired. Of course, the tunnel alone is probably a firing offence, but there's no need to make it obvious.

3

Suppose you have

work:~#
home:~#

And work:~# is the firewall you can't control

When you write server, I see from context (ssh -D 4096 server), that you mean SSH server. (and not e.g. VNC server). You should specify really, it's clearer. Normally if you have an SSH server it'd be on either work or home. It should be on the computer with the firewall that you can control, that is, Home.

You'd also typically have a regular server that you want to reach, and that's normally not an SSH server. Though it can be, there's a question with a great example of where one might want it to be.

Perhaps you can explain more what server:~# is, but i'm going to skip it out in the meantime 'cos it seems unncecessary and it's not clear what you mean by it 'cos if you have an SSH server e.g. on work then you'd get a prompt work:~#

So what you do is

From the one you can't control i.e. work, you make an outgoing connection. 'cos the firewall lets them out.

home:~# START VNC server on e.g. 5901
home:~# START SSHD SERVER on e.g. port 80 <-- whatever the command is to start your sshd.
work:~# ssh -R 1234:127.0.0.1:5901 user@homeip -p 80
home:~# vncviewer 127.0.0.1:1234

Home sees work.

really the switches to know for SSH are -L, -R and -D

And if you are connecting the client program to the listening port in such a way that the client program is on a different machine to your listening port, then it needs to be -R *:1234:127.0.0.1:5901 or 0.0.0.0:1234:127.0.0.1:5901

Though bear in mind, that's for something like VNC, but if you did it for HTTP you'd only be able to view one site. There is -D which as you see is local.

Some people are at home and want to access a server at work, and that server is behind a firewall they don't control.

But if you want internet access, then you're at work, wanting to access a server at home..

Why on earth can't you do that?

Try running the SSHD server on port 80 or port 443 at home, and do work~:#ssh homeip -p 443

3
