How do I print the value of %eax and %ebp?

(gdb) p $eax
$1 = void

1

7 Answers

info registers shows all the registers; info registers eax shows just the register eax. The command can be abbreviated as i r

5

If you're trying to print a specific register in GDB, you have to omit the % sign. For example,

info registers eip

If your executable is 64 bit, the registers start with r. Starting them with e is not valid.

info registers rip

Those can be abbreviated to:

i r rip

There is also:

info all-registers

Then you can get the register name you are interested in -- very useful for finding platform-specific registers (like NEON Q... on ARM).

2

• If only want check it once, info registers show registers.
• If only want watch one register, for example, display $esp continue display esp registers in gdb command line.
• If want watch all registers, layout regs continue show registers, with TUI mode.

Gdb commands:

• i r <register_name>: print a single register, e.g i r rax, i r eax
• i r <register_name_1> <register_name_2> ...: print multiple registers, e.g i r rdi rsi,
• i r: print all register except floating point & vector register (xmm, ymm, zmm).
• i r a: print all register, include floating point & vector register (xmm, ymm, zmm).
• i r f: print all FPU floating registers (st0-7 and a few other f*)

Other register groups besides a (all) and f (float) can be found with:

maint print reggroups

as documented at:

Tips:

• xmm0 ~ xmm15, are 128 bits, almost every modern machine has it, they are released in 1999.
• ymm0 ~ ymm15, are 256 bits, new machine usually have it, they are released in 2011.
• zmm0 ~ zmm31, are 512 bits, normal pc probably don't have it (as the year 2016), they are released in 2013, and mainly used in servers so far.
• Only one serial of xmm / ymm / zmm will be shown, because they are the same registers in different mode. On my machine ymm is shown.

p $eax works as of GDB 7.7.1

Tested as of GDB 7.7.1, the command you've tried works:

set $eax = 0
p $eax
# $1 = 0
set $eax = 1
p $eax
# $2 = 1

This syntax can also be used to select between different union members e.g. for ARM floating point registers that can be either floating point or integers:

p $s0.f
p $s0.u

From the docs:

Any name preceded by ‘$’ can be used for a convenience variable, unless it is one of the predefined machine-specific register names.

and:

You can refer to machine register contents, in expressions, as variables with names starting with ‘$’. The names of registers are different for each machine; use info registers to see the names used on your machine.

But I haven't had much luck with control registers so far: OSDev 2012 || 2005 feature request || alt.lang.asm 2013

ARM floating point registers

See:

3

Easiest for me is:

(gdb) x/x $eax

First x stands for examine and second x is hex. You can see other formats using:

(gdb) help x

You can easily print strings with x/s $eax or return addresses with x/a $ebp+4.
