Just setup a new Azure subscription, and i'm stumped trying to troubleshoot why I can't ping any local VMWare machines from a Azure VM. After successfully setting up an IPSec Site-To-Site VPN.

I am doing this as a learning exercise to setup a home lab, and working on my crappy networking skills :(

I have the following setup:

• Esxi Server with a VM (Portal) on a vlan50 network
• Managed switch with vlan50 tagging
• pfSense router with 192.168.20.1/24 address on vlan50
• A working IPSec tunnel from my lab 192.168.20.0/24 to Azure virtual network 192.168.50.0/24

So for testing I created 1 VM in on-prem lab, and 1 VM in Azure

• On-prem VM [Portal] - 192.168.20.2 vlan50
• Azure VM [TestVM] - 192.168.50.100 (no vlan)

From the Portal Server, I can ping the local gateway 192.168.20.1,

And from the pfSense I can ping the Azure VM:

Ping from pfSense to AzureVM

And from the Azure Server, I can ping the 192.168.20.1 interface.

Ping from Azure to pfSense interface, not enough reputation :(

However, the VMs cannot see each other\ping each other. I cannot understand this. I added rules in both IPSec & the vlan50 to allow all access to each subnet. I have a feeling my issue is either a Firewall rule, or vlan tag?

Here are some interesting things I'm noticing while troubleshooting:

1. I don't see any ICMP traffic on the vlan50 interface when successfully pinging from pfSense to AzureVM
2. When (unsuccessfully) pinging from AzureVM to Portal box, I see unanswered ICMP requests from 192.168.50.100 when listening on pfSense box on the vlan50 interface

I also created a very crude network outline with screenshots of the configuration I have setup: Crude Network layout

1 Answer

Doh! I found the answer was the fact that my Portal machine that's on-premise has multiple NIC, and the default Gateway doesn't know that route. I added a static gateway and was able to successfully ping each machine
