I created a Azure file share and I am able to connect to it using map network drive in my laptop having windows 10. I created a hello-world spring boot application with volume mount configurations for azure file share and trying to deploy in Kubernetes in docker-desktop. But my pod doesn't starts -

hello-world-9d7479c4d-26mv2 0/1 ContainerCreating 0 15s

Here is the error I can see in events when I describe the POD -

Events: Type Reason Age From Message ---- ------ ---- ---- ------- Normal Scheduled 9h Successfully assigned default/hello-world-9d7479c4d-26mv2 to docker-desktop Warning FailedMount 9h (x7 over 9h) kubelet, docker-desktop MountVolume.SetUp failed for volume "fileshare-pv" : mount failed: exit status 32
Mounting command: mount
Mounting arguments: -t cifs -o file_mode=0777,dir_mode=0777,vers=3.0,<masked> // /var/lib/kubelet/pods/425012d1-13ee-4c40-bf40-d2f7ccfe5954/volumes/kubernetes.io~azure-file/fileshare-pv
Output: mount: /var/lib/kubelet/pods/425012d1-13ee-4c40-bf40-d2f7ccfe5954/volumes/kubernetes.io~azure-file/fileshare-pv: bad option; for several filesystems (e.g. nfs, cifs) you might need a /sbin/mount.<type> helper program.

Then I updated my Dockerfile to install cifs-utils -

FROM ubuntu:16.04
# Install Java
RUN apt-get update && \ apt-get install -y openjdk-8-jdk && \ apt-get install -y ant && \ apt-get install -y cifs-utils && \ apt-get clean;
ENV PORT 8080
EXPOSE 8080
COPY target/*.jar /opt/app.jar
WORKDIR /opt
CMD ["java", "-jar", "app.jar"]

Still that error doesn't go. I googled a lot for solution but no luck. Is there any limitation in using azure file share with kubernates container in docker-desktop [windows machine]?

Here are my K8 configurations -

secret.yaml

apiVersion: v1
kind: Secret
metadata: name: storage-secret namespace: default
type: Opaque
data: azurestorageaccountname: BASE64-encoded-account-name azurestorageaccountkey: BASE64-encoded-account-key

pv.yaml

apiVersion: v1
kind: PersistentVolume
metadata: name: fileshare-pv labels: usage: fileshare-pv
spec: capacity: storage: 1Gi accessModes: - ReadWriteMany persistentVolumeReclaimPolicy: Retain azureFile: secretName: storage-secret shareName: myshare readOnly: false

pvc.yaml

kind: PersistentVolumeClaim
apiVersion: v1
metadata: name: fileshare-pvc namespace: default # Set this annotation to NOT let Kubernetes automatically create # a persistent volume for this volume claim. annotations: ""
spec: accessModes: - ReadWriteMany resources: requests: storage: 1Gi selector: # To make sure we match the claim with the exact volume, match the label matchLabels: usage: fileshare-pv

deployment.yaml

apiVersion: apps/v1
kind: Deployment
metadata: name: hello-world namespace: default labels: app: hello-world
spec: replicas: 1 selector: matchLabels: app: hello-world template: metadata: labels: app: hello-world spec: containers: - name: hello-world-pod image: 'hello-world-k8:1.0' volumeMounts: - name: azure mountPath: /azureshare ports: - containerPort: 8080 volumes: - name: azure persistentVolumeClaim: claimName: fileshare-pvc
---
apiVersion: v1
kind: Service
metadata: name: hello-world-service namespace: default
spec: selector: app: hello-world ports: - name: http protocol: TCP port: 8080 targetPort: 8080 type: LoadBalancer

2 Answers

You likely need to install a package that knows how to mount that file system. For NFS this may be nfs-common with Debian/Ubuntu.

sudo apt update && sudo apt install nfs-common -y

2

It happened on my ubuntu server 22.04 LTS machine. Use sudo apt install nfs-common or sudo apt install nfs-utils to resolve it.
