It's been known to me that RAM on Asus E200HA is soldered within the motherboard, thus not upgradable. lshw shows though there are two slots optional but only one used. The question is: is there a way to use that empty slot in a user friendly manner, or is this info just useless?

1 Answer

Unless your system has actually wired the second memory channel from the CPU to a DIMM slot that information is useless to you. All it means is that your CPU has pins to connect to a second memory module, not that you have space to fit one.

Your motherboard manual has no mention of memory upgrades, and Mr Memoryand Crucial both state that your memory is not upgradable.

---

The following two images from Chipbay.uk show your motherboard in detail. Your current 4GB of memory will be the two chips on the left of the CPU on the top image and the right of the CPU area on the bottom image.

You have no place for a DIMM to be fitted, nor do you have any area where extra chips could be soldered.

You have a single channel of RAM connected and no physical way to connect more RAM or to replace the current RAM without first desoldering the current chips. Getting a professional to do the work, or even to source replacements that might work, would likely cost more than the computer is worth.

4
